Garmin VHF115 VHF RADIO - OPENED BOX

Please note this is in great condition. The box has been opened and the installation instructions are missing.

Stay connected and safe on the water with the Garmin VHF 115 Marine Radio (Model: 010-02096-00). This fixed-mount radio delivers 25 watts of transmit power and features built-in GPS, providing reliable communication for fishermen, sailors, and cruisers. With standard Class D Digital Selective Calling (DSC) functionality, you can send distress calls or direct calls using a user-programmed MMSI, improving your chances of a rapid rescue in emergency situations. The radio covers all U.S., Canadian, and international marine channels, along with 10 NOAA weather channels, keeping you informed and connected wherever your journey takes you.

Easy to install and use, the VHF 115 plugs directly into compatible Garmin chartplotters and multifunction displays via the NMEA 2000® network, with additional support for NMEA 0183 devices. Its sleek design complements popular Garmin GPSMAP® chartplotters, including the 7x2/9x2, 10x2/12x2, 7400/7600, and 8400/8600 series, integrating seamlessly into your helm while delivering professional-grade marine communication.

Key Features - Garmin VHF 115

Model: 010-02096-00
Fixed-Mount Design: Easy installation on boats and compatible with Garmin chartplotters and MFDs
Plug & Play: Connects via the NMEA 2000® network, also compatible with NMEA 0183
Transmit Power: 25 watts for reliable communication
Built-in GPS: Supports location tracking for enhanced safety
Digital Selective Calling (DSC): Standard Class D functionality for distress and direct calling with user-programmed MMSI
Channel Coverage: All U.S., Canadian, and international marine channels
NOAA Weather Channels: 10 channels for up-to-date weather alerts
Emergency Functionality: DSC may improve rescue response time
Helm Integration: Designed to complement Garmin GPSMAP® chartplotters (7x2/9x2, 10x2/12x2, 7400/7600, 8400/8600 series)

What is included?

VHF 115 marine radio
Bail mount with knobs and mounting hardware
Protective cover
Trim ring snap cover
Flush mount gasket
Power cable

Specification	Details
Unit Dimensions	HxWxD: 3.4" x 6.7" x 5.8" (8.5 x 17.0 x 14.6 cm)
Weight	43.8 oz. (1.24 kg)
Water Rating	IPX7
Temperature Range	Operating: -15°C to 70°C (5°F to 158°F); Storage: -20°C to 70°C (-4°F to 158°F)
Compass-safe Distance	27.6" (70 cm)
NMEA 2000	Yes
NMEA 0183	Yes
Digital Selective Calling	Class D
Frequency Bands	All USA, Canadian, and International marine channels; 10 NOAA weather channels
Operating Voltage	12.0 Vdc
Current Draw	Standby: 350 mA; Receive: 600 mA; Transmit: 2.0 A to 6.0 A (1 W to 25 W)
Frequency Range	156.050 MHz to 163.275 MHz (including WX channels)
External Speaker Impedance	4 Ω
Antenna Connector	SO-239 (50 Ω)
Maximum Antenna Gain	9 dBi
