Description
ER-TFT080-2 is 800x600 dots 8" color tft lcd display with HX8264 driver IC, optional 4-wire resistive touch panel with connector and USB port controller board, optional capacitive touch panel with connector, superior display quality,super wide view angle and easily controlled by MCU such as 8051, PIC, AVR, ARDUINO, ARM and Raspberry PI.
It can be used in any embedded systems,car,mp4,gps,industrial device,security and hand-held equipment which requires display in high quality and colorful image.It supports rgb interface. FPC with zif connector is easily to assemble or remove.
Video_ER-TFT080-2
Low Cost SPI 8 inch 800x600 TFT Touch Display Module for Arduino
Video will open in a new window
Using the eBay App? Paste link into a browser window:
8 inch Series TFT Display List ↓
Display Part Number | Description |
8"TFT LCD 800x600 Dots Display | |
8"TFT LCD 800x600 Dots Display with VGA/Video/HDMI Driver Board | |
8"TFT LCD 800x600 Dots Display with Small HDMI Driver Board | |
8"TFT LCD 800x480 Dots Display with VGA/Video/HDMI Driver Board | |
8"TFT LCD 800x480 Dots Display with Small HDMI Driver Board |
What's included in the package ↓
Num | Accessory Name | Qty |
1 | 8 inch TFT LCD 800x600 Pixels Display | 1 |
2 | ZIF (FPC) Connector | 1 |
Optional Accessory List (Click the part number to buy accessories) ↓
Part Number | Description |
8 inch Capacitive Touch Panel with Connector
|
|
8 inch Resistive Touch Panel | |
4-Wire Resistive Touch USB Port Controller Driver Board |
*We mount touch panel on display by default if the touch panel is purchased together with the display.
Ebay doesn't allow listings to contain external links,so the documents link may be invalid. Please copy the below entire link to your browser for checking our documents(at the bottom of the page) or for bulk order.
https://www.buydisplay.com/8-inch-tft-lcd-display-ej080na-05a-800x600-8-inch-tft-lcd-screen-50-pins
Datasheet - TFT LCD Display,Controller,Connector ↓
Format | Documents Name (Downloadable) | Version | Language | Update Date | Size |
 | 1.0 | English | May-17-2019 | 538K | |
| 1.0 | English | Feb-01-2011 | 1.9M | |
| 1.0 | English | Jul-26-2012 | 273K |
| Gross Weight (kg) | 0.3680 |
|---|---|
| Manufacturer | EastRising |
| Continuity Supply | We promise the long term continuity supply for this product no less than 10 years since 2019. |
| Part Number | ER-TFT080-2 |
| Display Format | 800x600 Pixels |
| Interface | RGB |
| IC or Equivalent | HX8264 |
| Appearance | RGB on Black |
| Diagonal Size | 8.0“ |
| Connection | FPC-Connector |
| Outline Dimension | 183.00(W)x141.00(H)x5.6(T)mm |
| Visual Area | 164.80(W)x1240.3(H)mm |
| Active Area | 162.00(W)x121.50(H)mm |
| Character Size | No |
| Dot (Pixel) Size | No |
| Dot (Pixel) Pitch | 0.2025(W)x0.2531(H)mm |
| IC Package | COG |
| Display Type | TFT-LCD Color |
| Touch Panel Optional | Yes |
| Sunlight Readable | No |
| Response Time(Typ) | 15ms |
| Contrast Ratio(Typ) | 500:1 |
| Colors | 65K/262K/16.7M |
| Viewing Direction | No |
| Viewing Angle Range | Left:70.0 , Right:70.0 , Up:50.0 , Down:70.0 degree |
| Brightness(Typ) | 420cd/m2 |
| Backlight Color | White Color |
| Backlight Current (Typ) | No |
| Power Supply(Typ) | 3.3V |
| Supply Current for LCM(Max) | No |
| Operating Temperature | -20℃~70℃ |
| Storage Temperature | -30℃~80℃ |
| Series Number | ER-TFT080-2 |
