Package Includes:
1 X 3-Row Aluminum Radiator
1 X Radiator Cap
1 X Aluminum Shroud
1 X 14" Fan (Includes mounting kits)

Application:
This Radiator Fits:
For Toyota Land Cruiser FJ40 FJ45 1958-1984
Fits 3.9L and 4.2L I6 GAS Engine

This Radiator Size:
Material: Aluminum
High Performance Racing Spec.
3-Row of tubes Core Racing Design
Core size :17 " tall x 19.25" wide
Overall Size: 22" tall x 22.13" wide (with brackets)
Hose Locations:   In: Driver & Out: Passenger
Hose Fittings:    In: 1-1/2" & Out: 1-1/2"
Tank Wall Thickness: 0.08in.
Drain Plug Thread Size: M12 x 1.5mm.
Please Check the Size Before You Buy!

Aluminum Shroud+Fan:
Our custom-made aluminum fan shrouds are manufactured to fit our radiators. These fan shrouds are fabricated for use with our electric cooling fans but allow for use with most low profile electric fans.
The fan and the fan shroud effectively drive the heat over and out the engine compartment rather than thrusting it into the front of the engine. The fan shroud basically houses the fan blades securing it in place and keeping it from damaging the other engine components that may disturb the smooth and even operation of the engine. With excellent operating temperature management, allowable levels of engine temperature are stabilized. Investing in proper maintenance though will considerably benefit the ride and driving quality in maintaining the ideal working conditions of the engine.

Fan Specification:
Diameter: 14'' (Blade to Blade)
Voltage: DC 12 Volts
Wattage: 80W
Number of Blades: 8 S-Type blades
Maximum Fan CFM（Cubic Feet per Minute）: 2250cfm
Maximum Fan RPM（Revolution(s) Per Minute）: 2000±10%
Fan Thickness: 2.64"
S-Type Blade pull push design, to make air flow more efficient and bring more cooling Effect
Powerful 80 watt motor will keep your engine cool.

Description:
This aluminum radiator is designed to provide maximum cooling efficiency to prevent premature engine failure. Its light-weight, and high-heat transferring aluminum features a tube and fin design that, dramatically increases surface area that enables the heat to dissipate more efficiently. This Aluminum Radiator is at least 40% more efficient than stock ones. Most importantly, it has a much higher capacity for coolant than stock ones, which means that your cooling system will be more efficient and will be more resistant to temperature surges in racing applications.
