150*250 Jaw Crusher With Screen Stone Crusher Machinery 5500w 1-2t/h By Sea
Product Description
The small mobile diesel jaw crusher with vibrating screen max. feeding size is 210 mm, output size is 20-60 mm, capacity is 5-20 t/h. It can beak various stones, such as granite, basalt, limestone, river stone, sandstone, shale, iron ore, copper ore, building construction, construction wastes etc.
Details Images
Specification
|
Model
|
Feeder Opening Size(mm)
|
Max. Feeding Size (mm)
|
Discharging Opening Size(mm)
|
Capacity (t/h)
|
Motor Power (kw)
|
Overall Dimension (mm)
|
|
150x250
|
150x250
|
130
|
10-45
|
1-4
|
5.5
|
896x745x935
|
|
200x300
|
200x300
|
180
|
15-50
|
2-6
|
7.5
|
910x750x990
|
|
200x350
|
200x350
|
180
|
18-70
|
3-10
|
7.5
|
1000x870x990
|
|
250x400
|
250x400
|
210
|
25-60
|
5-20
|
15
|
1215x1240x1210
|
Working Principle
Through transmission of belts, the motor drives the eccentric shaft. Under drive of the eccentric shaft, the moving jaw does periodic motion towards the fixed jaw. When the space between the moving jaw and the fixed jaw reduces, the materials will be crushed. When the space between the moving jaw and the fixed increases, the final crushed materials will be discharged from the opening.
Note:
shipping by sea!
