VC837 Digital Multimeter DMM True RMS 6000 Auto Range Capacitance Resistance NCV



Features:

1. True RMS , non-contact voltage detect (NCV), relative value measurement,

frequency/duty cycle and data hold fucntion;

2. Unit symbol display, easy to read; Lighting function, backlight display

3. Auto power off when there is no measurement in 15 minutes;

4. Strong antimagnetic and anti-interferential performance;

Full function protection;

5. Large LCD display makes reading clear;

6. New type holster, streamlined design, comfortable handle;



Specification:

Basic function	Range	Basic   accuracy
DCV	200mV/2V/20V/200V/600V	±(0.5%+4)
ACV	6V/ 60V/ 600V/ 600V	±(0.8%+6)
DCA	600uA/ 6000uA/ 60mA/ 600mA/ 6A/ 10A	±(1.0%+5)
ACA	600uA/ 6000uA/ 60mA/ 600mA/ 6A/ 10A	±(1.5%+5)
Resistance	600/ 6k/ 60k/ 600k/ 6M/ 60M ohm	±(0.8%+1)
Capacitance	60nF/ 600nF/ 6uF/ 60uF/ 600uF/ 6mF/ 60mF	±(3.5%+8)
Frequency	10Hz/100Hz/1KHz/10KHz/100KHz/1MHz/10MHz	±(0.5%+4)
Centigrade temperature	-40°C~1000°C / 0°F~1832°F	±(0.8%+4)



Special function	VC837
True RMS	√
NCV	√
Backlight	√
Duty Cycle	1~99%
Continuity test	Approx. less than 50Ω, it displays “OL” if over 610Ω
Low battery indication	Approx less than 2.4V
Diode Test	0-3.3V, it displays   “OL” if over 3.3V
Function Protection	√
Data hold	√
Auto power off	Approx.15minutes
Torch Function	√
Input impendence	10MΩ
Sampling rate	3times/s
AC frequency response	40-2kHz
Operation way	Manual or auto   range
Max. display	6000
LCD size	65x28mm
Battery	3V  AAA×2(not include in shipping)
Power dissipation	Quiescent current approx. 2mA



Package:

1 x vc837 multimeter;

1 x pair test probe;

1 x pair test CLIP; (PLUS)

1 x temperature probe;

1 x manual;

(Kindly please be reminded: battery is not included because air post prohibition)
