Product Information

Engine Pro Valve spring Set fits Holden L76 L77 Gen IV Commodore VE VF VZ Statesman WM

Item Specifics
SKU: 02-1201-16
Returns: 30 Days
Ships From: Melbourne

Description

Engine Pro Valve spring Set fits Holden 6.0L L76 L77 Gen IV V8 OHV Commodore VE VF VZ Statesman WM Petrol

Engine Pro Valve spring
1.292" O.D., 135 lbs @ 1.800" (Beehive)

Notes

Outer Diameter Bottom 1.292"
Outer Diameter Top 1.062"
Inner Diameter Bottom 0.880"
Inner Diameter Top 0.650"
Seat Load Valve Closed 135 lbs
Seat Load Height 1.800"
Open Load Valve Open 330 lbs
Open Load Height 1.150"
Solid Height 1.110"
Max Lift 0.650"
Spring Rate 300 lbs
Spring Type Single Beehive
Material Chrome Silicone Vanadium Nickel
Quantity 16
*
Use With Retainer 03-1011-16, 03-1013-16, 03-1014-16
03-1015-16

Variations for this Engine

These are the different Variations for the Holden L76 L77 Gen IV OHV 6.0L V8 ULP Engine. Please check carefully you have selected the right part for your vehicle.

16 x SBI 160-1488 Valve spring Standard Replacement - LS1, L76 L77, L68, LSA
Engine Pro Set 02-1201-16 Valve spring 1.292" O.D., 135 lbs @ 1.800" (Beehive)
Engine Pro Set 02-1205-16 Valve spring 1.237" O.D., 110 lbs @ 1.700" (Beehive)
SBI 160-1488 Valve spring Standard Replacement - LS1, L76 L77, L68, LSA

Suitable For

Bedford
Series E 308 Red 5.0L OHV V8
Chevrolet
Bel Air 283 4.6L OHV V8
Bel Air 307 5.0L OHV V8
Bel Air 327 5.4L OHV V8
Bel Air 350 5.7L OHV V8
C20 305 5.0L OHV V8
Camaro 350 5.7L OHV V8
Corvette C2 327 5.4L OHV V8
Corvette C3 350 5.7L OHV V8
Corvette C3 L98 LT1 LT5 Gen IV 6.0L OHV V8
Corvette C4 L98 LT1 LT5 Gen IV 6.0L OHV V8
Corvette C5 LS1 GenIII C4B 5.7L OHV V8
Corvette C6 LS2 GenIV 6.0L OHV V8
Corvette C6 LS3 6.2L OHV V8
G20 350 5.7L OHV V8
Impala 283 4.6L OHV V8
Impala 327 5.4L OHV V8
M SILVERADO 305 5.0L OHV V8
Ssr LS2 GenIV 6.0L OHV V8
Suburban RCWG 350 Vortec LM1 5.7L OHV V8
Tahoe LT RCWG 350 Vortec LM1 5.7L OHV V8
Various 302 4.9L OHV V8
Various 383 6.3L OHV V8
Holden
Adventra VY LS1 GenIII C4B 5.7L OHV V8
Adventra VZ LS1 GenIII C4B 5.7L OHV V8
Commodore VB 253 4.2L Red 4.2L OHV V8
Commodore VB 308 Red 5.0L OHV V8
Commodore VB 355 Stroker 5.8L OHV V8
Commodore VC 253 4.2L Blue 4.2L OHV V8
Commodore VC 308 Blue Black 5.0L OHV V8
Commodore VE L76 L77 Gen IV 6.0L OHV V8
Commodore VE L98 LT1 LT5 Gen IV 6.0L OHV V8
Commodore VF L76 L77 Gen IV 6.0L OHV V8
Commodore VF LS3 6.2L OHV V8
Commodore VG 304 5.0L OHV V8
Commodore VH 253 4.2L Blue 4.2L OHV V8
Commodore VH 308 Blue Black 5.0L OHV V8
Commodore VK 308 Blue Black 5.0L OHV V8
Commodore VL 304 5.0L OHV V8
Commodore VL 308 Blue Black 5.0L OHV V8
Commodore VN 304 5.0L OHV V8
Commodore VP 304 5.0L OHV V8
Commodore VR 304 5.0L OHV V8
Commodore VS 304 5.0L OHV V8
Commodore VT 304 5.0L OHV V8
Commodore VU LS1 GenIII C4B 5.7L OHV V8
Commodore VX LS1 GenIII C4B 5.7L OHV V8
Commodore VY LS1 GenIII C4B 5.7L OHV V8
Commodore VZ L76 L77 Gen IV 6.0L OHV V8
Commodore VZ L98 LT1 LT5 Gen IV 6.0L OHV V8
Commodore VZ LS1 GenIII C4B 5.7L OHV V8
Crewman VY LS1 GenIII C4B 5.7L OHV V8
Crewman VZ LS1 GenIII C4B 5.7L OHV V8
Crewman VZ LS2 GenIV 6.0L OHV V8
Hg HG 253 4.2L Red 4.2L OHV V8
Hg HG 308 Red 5.0L OHV V8
Kingswood HG 253 4.2L Red 4.2L OHV V8
Kingswood HG 308 Red 5.0L OHV V8
Kingswood HG 350 5.7L OHV V8
Kingswood HJ 253 4.2L Red 4.2L OHV V8
Kingswood HJ 308 Red 5.0L OHV V8
Kingswood HK 307 5.0L OHV V8
Kingswood HK 327 5.4L OHV V8
Kingswood HK 350 5.7L OHV V8
Kingswood HK 355 Stroker 5.8L OHV V8
Kingswood HQ 253 4.2L Red 4.2L OHV V8
Kingswood HQ 307 5.0L OHV V8
Kingswood HQ 308 Red 5.0L OHV V8
Kingswood HQ 327 5.4L OHV V8
Kingswood HQ 350 5.7L OHV V8
Kingswood HQ 355 Stroker 5.8L OHV V8
Kingswood HT 253 4.2L Red 4.2L OHV V8
Kingswood HT 307 5.0L OHV V8
Kingswood HT 308 Red 5.0L OHV V8
Kingswood HT 327 5.4L OHV V8
Kingswood HT 350 5.7L OHV V8
Kingswood HT 355 Stroker 5.8L OHV V8
Kingswood HX 253 4.2L Red 4.2L OHV V8
Kingswood HX 308 Red 5.0L OHV V8
Kingswood HX 355 Stroker 5.8L OHV V8
Kingswood HZ 253 4.2L Red 4.2L OHV V8
Kingswood HZ 308 Red 5.0L OHV V8
Kingswood HZ 355 Stroker 5.8L OHV V8
Monaro HG 253 4.2L Red 4.2L OHV V8
Monaro HG 308 Red 5.0L OHV V8
Monaro HG 350 5.7L OHV V8
Monaro HJ 253 4.2L Red 4.2L OHV V8
Monaro HJ 308 Red 5.0L OHV V8
Monaro HK 307 5.0L OHV V8
Monaro HK 327 5.4L OHV V8
Monaro HQ 253 4.2L Red 4.2L OHV V8
Monaro HQ 308 Red 5.0L OHV V8
Monaro HQ 350 5.7L OHV V8
Monaro HT 253 4.2L Red 4.2L OHV V8
Monaro HT 307 5.0L OHV V8
Monaro HT 308 Red 5.0L OHV V8
Monaro HT 350 5.7L OHV V8
Monaro HX 253 4.2L Red 4.2L OHV V8
Monaro HX 308 Red 5.0L OHV V8
Monaro HZ 253 4.2L Red 4.2L OHV V8
Monaro HZ 308 Red 5.0L OHV V8
Monaro V2 LS1 GenIII C4B 5.7L OHV V8
Monaro VZ LS1 GenIII C4B 5.7L OHV V8
One Tonner HJ 253 4.2L Red 4.2L OHV V8
One Tonner HQ 253 4.2L Red 4.2L OHV V8
One Tonner HX 253 4.2L Red 4.2L OHV V8
One Tonner HZ 253 4.2L Red 4.2L OHV V8
One Tonner VY LS1 GenIII C4B 5.7L OHV V8
One Tonner WB 253 4.2L Red 4.2L OHV V8
One Tonner WB 308 Red 5.0L OHV V8
One Tonner WB 355 Stroker 5.8L OHV V8
Statesman HJ 308 Red 5.0L OHV V8
Statesman HJ 355 Stroker 5.8L OHV V8
Statesman HQ 253 4.2L Red 4.2L OHV V8
Statesman HQ 308 Red 5.0L OHV V8
Statesman HQ 350 5.7L OHV V8
Statesman HQ 355 Stroker 5.8L OHV V8
Statesman HX 308 Red 5.0L OHV V8
Statesman HX 355 Stroker 5.8L OHV V8
Statesman HZ 308 Red 5.0L OHV V8
Statesman HZ 355 Stroker 5.8L OHV V8
Statesman VQ 304 5.0L OHV V8
Statesman VR 304 5.0L OHV V8
Statesman VS 304 5.0L OHV V8
Statesman WB 253 4.2L Blue 4.2L OHV V8
Statesman WB 308 Red 5.0L OHV V8
Statesman WB 355 Stroker 5.8L OHV V8
Statesman WH LS1 GenIII C4B 5.7L OHV V8
Statesman WK LS1 GenIII C4B 5.7L OHV V8
Statesman WL LS1 GenIII C4B 5.7L OHV V8
Statesman WM L76 L77 Gen IV 6.0L OHV V8
Statesman WM L98 LT1 LT5 Gen IV 6.0L OHV V8
Suburban K8 RCWG 350 Vortec LM1 5.7L OHV V8
Torana LH 253 4.2L Red 4.2L OHV V8
Torana LH 308 Red 5.0L OHV V8
Torana LX 253 4.2L Red 4.2L OHV V8
Torana LX 308 Red 5.0L OHV V8
Various LSA 6.2L OHV V8
HSV
Avalanche VY LS1 GenIII C4B 5.7L OHV V8
Avalanche VZ LS1 GenIII C4B 5.7L OHV V8
Clubsport VN 304 5.0L OHV V8
Clubsport VP 304 5.0L OHV V8
Clubsport VR 304 5.0L OHV V8
Clubsport VS 304 5.0L OHV V8
Clubsport VT 304 5.0L OHV V8
Clubsport VT LS1 GenIII C4B 5.7L OHV V8
Clubsport VX LS1 GenIII C4B 5.7L OHV V8
Clubsport VY LS1 GenIII C4B 5.7L OHV V8
Clubsport VZ LS2 GenIV 6.0L OHV V8
Clubsport VZ LS3 6.2L OHV V8
Coupe VZ LS1 GenIII C4B 5.7L OHV V8
Coupe VZ LS2 GenIV 6.0L OHV V8
Grange VS 304 5.0L OHV V8
Grange WH LS1 GenIII C4B 5.7L OHV V8
Grange WK LS1 GenIII C4B 5.7L OHV V8
Grange WL LS2 GenIV 6.0L OHV V8
Grange WM LS2 GenIV 6.0L OHV V8
Grange WM LS3 6.2L OHV V8
Gts VP 304 5.0L OHV V8
Gts VR 304 5.0L OHV V8
Gts VS 304 5.0L OHV V8
Gts VT 304 5.0L OHV V8
Gts VT LS1 GenIII C4B 5.7L OHV V8
Gts VX LS1 GenIII C4B 5.7L OHV V8
Gts VY LS1 GenIII C4B 5.7L OHV V8
Gts-r VS 304 5.0L OHV V8
Ls VP 304 5.0L OHV V8
Maloo VE LS3 6.2L OHV V8
Maloo VG 304 5.0L OHV V8
Maloo VP 304 5.0L OHV V8
Maloo VR 304 5.0L OHV V8
Maloo VS 304 5.0L OHV V8
Maloo VU LS1 GenIII C4B 5.7L OHV V8
Maloo VY LS1 GenIII C4B 5.7L OHV V8
Maloo VZ LS2 GenIV 6.0L OHV V8
Manta VS 304 5.0L OHV V8
Senator VE LS3 6.2L OHV V8
Senator VP 304 5.0L OHV V8
Senator VR 304 5.0L OHV V8
Senator VT 304 5.0L OHV V8
Senator VT LS1 GenIII C4B 5.7L OHV V8
Senator VX LS1 GenIII C4B 5.7L OHV V8
Senator VY LS1 GenIII C4B 5.7L OHV V8
Senator VZ LS2 GenIV 6.0L OHV V8
Sports VP 304 5.0L OHV V8
Vx GTO LS1 GenIII C4B 5.7L OHV V8
Humber
Avalanche VY LS1 GenIII C4B 5.7L OHV V8
Avalanche VZ LS1 GenIII C4B 5.7L OHV V8
Clubsport VN 304 5.0L OHV V8
Clubsport VP 304 5.0L OHV V8
Clubsport VR 304 5.0L OHV V8
Clubsport VS 304 5.0L OHV V8
Clubsport VT 304 5.0L OHV V8
Clubsport VT LS1 GenIII C4B 5.7L OHV V8
Clubsport VX LS1 GenIII C4B 5.7L OHV V8
Clubsport VY LS1 GenIII C4B 5.7L OHV V8
Clubsport VZ LS2 GenIV 6.0L OHV V8
Clubsport VZ LS3 6.2L OHV V8
Coupe VZ LS1 GenIII C4B 5.7L OHV V8
Coupe VZ LS2 GenIV 6.0L OHV V8
Grange VS 304 5.0L OHV V8
Grange WH LS1 GenIII C4B 5.7L OHV V8
Grange WK LS1 GenIII C4B 5.7L OHV V8
Grange WL LS2 GenIV 6.0L OHV V8
Grange WM LS2 GenIV 6.0L OHV V8
Grange WM LS3 6.2L OHV V8
Gts VP 304 5.0L OHV V8
Gts VR 304 5.0L OHV V8
Gts VS 304 5.0L OHV V8
Gts VT 304 5.0L OHV V8
Gts VT LS1 GenIII C4B 5.7L OHV V8
Gts VX LS1 GenIII C4B 5.7L OHV V8
Gts VY LS1 GenIII C4B 5.7L OHV V8
Gts-r VS 304 5.0L OHV V8
Ls VP 304 5.0L OHV V8
Maloo VE LS3 6.2L OHV V8
Maloo VG 304 5.0L OHV V8
Maloo VP 304 5.0L OHV V8
Maloo VR 304 5.0L OHV V8
Maloo VS 304 5.0L OHV V8
Maloo VU LS1 GenIII C4B 5.7L OHV V8
Maloo VY LS1 GenIII C4B 5.7L OHV V8
Maloo VZ LS2 GenIV 6.0L OHV V8
Manta VS 304 5.0L OHV V8
Senator VE LS3 6.2L OHV V8
Senator VP 304 5.0L OHV V8
Senator VR 304 5.0L OHV V8
Senator VT 304 5.0L OHV V8
Senator VT LS1 GenIII C4B 5.7L OHV V8
Senator VX LS1 GenIII C4B 5.7L OHV V8
Senator VY LS1 GenIII C4B 5.7L OHV V8
Senator VZ LS2 GenIV 6.0L OHV V8
Sports VP 304 5.0L OHV V8
Vx GTO LS1 GenIII C4B 5.7L OHV V8
Pontiac
Firebird 305 5.0L OHV V8
Firebird 350 5.7L OHV V8
Firebird 400 6.6L OHV V8
Firebird L98 LT1 LT5 Gen IV 6.0L OHV V8
Firebird RCWG 350 Vortec LM1 5.7L OHV V8
Studebaker
Gran Turismo/hawk/lark 283 4.6L OHV V8

Other Parts for this Engine

These are the different parts available for the Holden L76 L77 Gen IV OHV 6.0L V8 ULP Engine

Camshaft Bearings
Durabond (CHP-23T) Camshaft bearing set 2nd Design 2003 On - Calico Coated
Durabond (CHP-25T) Camshaft bearing set Suits 2nd and 3rd Design 2003 On - Calico Coated
Camshaft Gears
Nason S-894 Camshaft gear Single Row - 1 Bolt Cam Gear - Multi Trigger Sensor
Conrod Bearings
Conversion Gasket Sets
Crankshaft Gears
Drive Belt Ancillaries
Exhaust Gaskets
Head Bolts and Studs
Nason NHBS140 Head bolt set Suits Engines From 2004-On With 2 Different Length Bolts
Head Gaskets
Inlet Manifold Gasket
Lifters
16 x Delphi RHT2148-USA Lifter Roller Hydraulic Lifter Made in USA - Delphi
16 x Delphi RHT2150-USA Lifter Suits AFM engines only- see notes
Delphi RHT2148-USA Lifter Roller Hydraulic Lifter Made in USA - Delphi
Delphi RHT2150-USA Lifter Suits AFM engines only- see notes
Main Bearings
Misc Gaskets
Miscellaneous
Engine Pro 04-1007-32 Valve collet 8mm Stem, 7 Deg - Chrome Moly
SBI 121-1085 Valve collet Suits 8mm Stem, 1 Round Bead
Oil Pumps
Melling 10355 Oil pump Standard Volume - L76/L77 AFM Engines & LSA
Piston Rings Cast
Rear Main Seals
Sump Gasket Sets
Timing Belt Tensioners and Guides
Timing Chains
Valve Cover Gaskets
Valve Guides
8 x Nason Inlet PVG544 Valve guide Bronze Guide- OD 0.502" x ID 0.310" x Length 2.130"
Nason Inlet PVG544 Valve guide Bronze Guide- OD 0.502" x ID 0.310" x Length 2.130"
Valve Spring Retainers
Engine Pro 03-1011-16 Valve spring retainer Spring O.D. 1.055" Beehive Spring
Engine Pro 03-1017-16 Valve spring retainer Spring O.D. 1.275" - 1.325"
Valve Springs
16 x SBI 160-1488 Valve spring Standard Replacement - LS1, L76 L77, L68, LSA
Engine Pro Set 02-1201-16 Valve spring 1.292" O.D., 135 lbs @ 1.800" (Beehive)
Engine Pro Set 02-1205-16 Valve spring 1.237" O.D., 110 lbs @ 1.700" (Beehive)
SBI 160-1488 Valve spring Standard Replacement - LS1, L76 L77, L68, LSA
Valves-Exhaust
Valves-Inlet
Water Pumps
Nason W1005HD Water pump Heavy Duty Type With Dome Pulley-See Notes
Nason W1005HDTH Water pump Heavy Duty Type With Dome Pulley- See Notes
Nason W1006HD Water pump Heavy Duty Type With Concaved Pulley- See Notes

Web Store Pty Ltd is a Melbourne based warehouse with thousands of the latest products at great prices. We hand select our range of Australian designed products from only the best local suppliers. We pride ourselves on our customer service and our friendly team are available to assist you through the buying process. When comparing prices know we only sell great quality items and our manufacturing passes strict quality checks before posting.

To ensure a smooth transaction, please follow the payment instructions laid out in the eBay system. If you are new to eBay and unsure how to purchase, please don't hesitate to get in contact with us as our Customer Service team will be happy to assist.

The simplest way to facilitate payment is via Mastercard, Visa, or Paypal via the Checkout process.

Please contact us if yous wish to pay via direct deposit and then we can supply our Account and BSB details.

If paying by bank deposit, please ensure you have your reference of your payment with your eBay user ID so we can identify the payment as yours. Failure to correctly reference your payment will cause a delay in our system which will ultimately delay the shipment of your order.
We check our bank accounts daily so as soon as your payment has cleared, we will start processing your order.

Our stock levels can change at any time. An order is only complete once payment has cleared. To prevent missing out, it's best to pay as soon as possible. Once a payment has cleared, 90% of products are dispatched within 1 business day, however please see our shipping page for estimated shipping times by state. Wedding Wish is not liable for any unidentified payments or delays of delivery due to failure to follow instructions during checkout.

For all payments outside of eBay, please ensure you send us the reference you used, the day and time you paid, and the amount deposited.

As always, if you have any questions, please get in contact with our Customer Service team who are more than happy to help.

We are happy to combine shipping on any orders. Individual listings with combined shipping will automatically calculate on checkout. When buying from multiple listings, please message us prior to purchase to confirm postage rates, be sure to include your postcode for accurate quoting and the items you are after. Express post is available on request for most orders, please note handing times will usually still apply.

Pre-arranged pickup is available from our warehouse in Dingley Village, Victoria. Please note that a handling time will still apply. Please call ahead or email us to ensure item is available for pickup.

POSTAGE & DISPATCH

After payment is cleared 90% of all items are dispatched within two business days, however please see below for estimated delivery times by state. Your item will be sent via courier or Australia Post depending on its size and weight.

Where goods are sent through Australia Post, the buyer may receive a knock on the door or a card in their letterbox indicating their item is available for pickup from their local post office.

A re-delivery fee will be charged to buyers for items that are undeliverable and/or returned due to incorrect delivery address or unsuccessful delivery.

Buyers have the full responsibility to provide us with the correct delivery address and mobile phone number on the checkout page before payment. Any changes to address after checkout will not be considered as valid.

Our staff work tirelessly to ensure customer satisfaction however we understand that on occasion issues do arise. If you have a problem with your purchase please contact us PRIOR to leaving feedback and we will do our best to rectify the situation.

Claims entered directly via this method will be given priority.

The fastest and best way to contact us is through the eBay messaging system. If you contact us out of eBay we may not see your message and our support team will be much slower in dealing with your issue. Thank you for your business!

Copyright (C) 2018 Web Store Pty Ltd. All Rights Reserved
