Product Description
Select Variant From Drop-Down Menu And "Add To Cart"
BLUE LED with BLUE switch covers (excluding ""NO COVER - MECHANISM ONLY" which is supplied without cover, as pictured)
Front Tank/Rear Tank On-On Variant Does Not Have LED's
For SPST Switches - Lower LED is illuminated for the "Dash Light" when powered, Top LED illuminates when switched "ON"*
- Up for On, Down for Off. Brackets () indicate momentary function. Momentary function will auto-return to Down/Off.
For DPDT 3 Way Switches - Lower LED and Top LED illuminate when switched "ON" respectively (up/down)
- Up for On, Down for On, Centre for Off. Brackets () indicate momentary function. Momentary function will auto-return to Centre/Off.
For On-On Switches - No LED
- Up for On, Down for On. No Off position. No LED
*Excludes Engine Start - No Dash Light LED (Lower)
All Switches are ON-OFF SPST, except the following: |"(ON)" indicates Momentary ON Function|
Up/Down Arrows ON-OFF-ON 3 WAY - ON-OFF-ON NON-MOMENTARY
Up/Down Arrows (ON)-OFF-(ON) 3 WAY - (ON)-OFF-(ON) MOMENTARY
Anchor Up/Anchor Down (ON)-OFF-(ON) 3 WAY - (ON)-OFF-(ON) MOMENTARY
Aux/Main Battery - ON-OFF-ON NON-MOMENTARY
Battery Link (ON)-OFF Momentary - (ON)-OFF MOMENTARY
Bilge Auto/Bilge On - ON-OFF-(ON) {NON-MOMENTARY UP for Auto, MOMENTARY DOWN for On}
Blank (ON)-OFF Momentary - (ON)-OFF MOMENTARY
Blank ON-OFF-ON 3 WAY - ON-OFF-ON NON-MOMENTARY
Blank (ON)-OFF-(ON) 3 Way - (ON)-OFF-(ON) MOMENTARY
Drive Tilt - (ON)-OFF-(ON) MOMENTARY
Engine Start - (ON)-OFF MOMENTARY
Front Tank/Rear Tank On-On - ON-ON NON-MOMENTARY NO LED. THIS SWITCH DOES NOT AN OFF POSITION
Glow Plugs (ON)-OFF Momentary - (ON)-OFF MOMENTARY
High Beam/Low Beam - ON-OFF-ON NON-MOMENTARY
Horn - (ON)-OFF MOMENTARY
Interior Light ON-OFF-ON 3 Way - ON-OFF-ON NON-MOMENTARY
Nav/Anchor Light - ON-OFF-ON NON-MOMENTARY
Open/Close (ON)-OFF-(ON) - (ON)-OFF-(ON) MOMENTARY
Reverse Lights ON-OFF-ON 3 WAY - ON-OFF-ON NON-MOMENTARY
Washer (Momentary) - (ON)-OFF MOMENTARY
Winch (In) Momentary - (ON)-OFF MOMENTARY
Winch (Out) Momentary - (ON)-OFF MOMENTARY
Winch In/Out - (ON)-OFF-(ON) MOMENTARY
Simple and Firm Clip-In Fitment
Rubber Gasket Seal For Mounting
For purchasing of multiple variants, simply select desired switch from Drop Down Menu, and Add To Cart.
Complete this process for all desired variants, then Check-Out.
Your cart will show selected variants. Please check this prior to completing purchase.
Item Specifications
Cut Out Required for Switch - 21.5mm (W) x 37.5mm (H)
Switch Surface Face Size - 24.5mm (W) x 49.5mm (H)
Voltage: 12v-24v
Maximum Rating: 10 Amps for 24V - 20 Amps for 12V
IP66
Fits a massive range of Vehicle/Boat/4x4 applications!
Wiring
5 Pin Switches (Terminals Labelled):
#2 - Incoming power from source
#3 - Outgoing (to relay, equipment or accessory - lights winch etc)
#8 - Upper main 'On' light Negative (-)
#7 - Lower "Dash" light Negative (-)
#6 - Lower "Dash" Light Positive (+)
6 Pin Switches On-On (Terminals Labelled):
#1 #4 - Outgoing To Relay/Equipment/Accessory (+)
#2 #5 - 12v in from Battery (+)
#3 #6 - Outgoing To Relay/Equipment/Accessory (+)
7 Pin Switches (Terminals Labelled):
#7 - Ground/Negative (-)
#1 #4 - Outgoing To Relay/Equipment/Accessory (+)
#2 #5 - 12v in from Battery (+)
#3 #6 - Outgoing To Relay/Equipment/Accessory (+)
