Compact. Reliable. Locker-Ready.

Looking for a lightweight, ultra-compact compressor to run your ARB Air Locker? The ARB CKSA12 is your go-to. Small enough to mount almost anywhere, this 12V on-board compressor delivers reliable performance for locker engagement and light-duty air needs out on the trail.

Whether you're adjusting tire pressures or just need a solid backup source of air, this unit gives you compressed air anywhere your truck goes. Plus, with a solid duty cycle and IP55 rating, it's built to handle the real-world abuse of off-road life.

KEY FEATURES:

• Hard anodized cylinder bores for reduced friction

• Teflon-impregnated carbon fiber piston seals for longer life

• Anodized heat-dissipating mounting bracket (can be rotated 180°)

• Built from lightweight, high-strength engineering materials

• Relocatable splash-resistant air filter

• Fully sealed for dust and moisture resistance (IP55 rating)

• Tested for current draw, flow rate, and leaks at the factory

• 3-year warranty from ARB

PERFORMANCE SPECS:

• Voltage: 12V

• Max Pressure: 100 PSI

• Max Amps: 9

• Duty Cycle: 35% @ 21/39 (21 minutes on / 39 off)

• Air Flow @ 0 PSI: 0.98 CFM

• Air Flow @ 29 PSI: 0.70 CFM

• Weight: 3.3 lbs

• Dimensions: 6.4" L x 3.5" W x 4.8" H

IDEAL FOR:

• Activating ARB Air Lockers

• Inflating small tires or camping gear (optional Pump-Up Kit recommended)

• Backup onboard air supply for light trail use

• Ultra-compact mounting in engine bays or cargo areas

Part Number: CKSA12

INSTALLATION NOTES:

• Mounts easily in tight spaces

• Air filter assembly can be relocated for cleaner intake air

• Add Pump-Up Kit (#171302) for inflation use

• Pair with ARB Air Lockers for full locker control

FREQUENTLY ASKED QUESTIONS:

Q: Is this compressor enough to inflate full-size off-road tires?
A: It's not built for large tire inflation. For that, check out the CKMA12 or CKMTA12 compressors.

Q: Can this power both front and rear lockers?
A: Yes, but with reduced duty cycle. It’s ideal for single or dual locker use with minimal air demand.

Q: Is this waterproof?
A: It’s IP55 rated — resistant to water spray and dust, but not submersible.

Q: Can it be mounted inside the vehicle?
A: Yes — it’s quiet and compact enough to mount in the cab or storage area.
