12G SDI Fiber Optic Extender 4K 60Hz 20Km SDI Transceiver Receiver Extender Kit 6G 3G HD SDI Fiber Extender SFP For PS4 DVD PC
Introduction
The fiber extender transmits 4K/12G SDI signal over long distances via a single fiber, support 16-channel embedded audio synchronization function; The multi-rate 12G-SDI interface is compatible with all SD, HD and Ultra HD formats and devices, up to 2160P@60Hz, including Class A and Class B devices. The Nsendato of transmitter is equipped with an optical fiber expansion slot, which can be installed with any standard 3G, 6G or 12G-SDI SFP optical fiber module, and can adapt to a variety of complex application environments by using the low cost optical cable widely used in computer networks to transmit SDI.The Nsendato of device has excellent image processing and output capabilities, enabling signal transmission smoother and more stable, it is a reliable, high-performance, Efficient 4K/12G-SDI signal extension
Features
1.Long-distance transmission of 4K/12G-SDI video and audio signals through optical fiber, up to 3-20KM
2.HD video signal resolution up to 2160P@60Hz
3.Support all-digital lossless transmission, 16-channel embedded audio and video synchronous transmission
4.Support local loop output; remote support two ways synchronous output
5.Support PAL/NTSC; Strong compatibility, can automatically identify and configure a variety of display modes
6.Supports plug and play and hot swap
7.Built-in automatic balancing system, the picture is smooth, clear and stable
8.Built-in ESD electrostatic protection circuit, all-round protection system
9.Easy to install, plug and play, no setup require
Specification:
Technical specifications:SMPTE Standards
Video bit rate:Max12 GB/s
Interface:BNC
Input/output cable specifications:≤10m（Belden 1694A Cable standard）
Video input/output impedance:75Ω
Video input/output voltage:1Vpp,Minimun：0.5Vpp/Max：1.5Vpp
SD Video format:525i59.94NTSC.625i50PAL
HD video format:720P50;720P59.94;720P60.1080P23.98;1080P24;1080P25;1080P29.97;1080P30;1080P50
1080P59.94;1080P60;1080PsF23.98;1080PsF24;1080PsF25;1080PsF29.97;1080PsF30;1080i50;1080i59.94;1080i60
2K and 4K video format:2K 23.98P/24P/25P;23.98PsF;/24PsF/25PsF;4K 23.98P/24P/25P/29.97P/30P/50P/ 59.94P/4K 60P;4K 23.98P/24P/25P
Fiber interface:LC
Fiber type:Single mode single fiber
Wave length:Single mode 1310nm；1550nm
Max transmission distance:Max distance up to 20KM
Power supply:C 5~12V/1A
Package
SDI Extender transmitter
SDI Extender receiver
power adapters
User manual
