- 7.9-inch Retina touch screen
- True Tone display technology
- Resolution: 2048 × 1536
- Maximum brightness: 2000 nits
- Compatible with other EVO II series drones
*Working frequency bands vary by country and model.
- 120dB @ 1m
- 88dB @ 60m
- 70dB @ 110m
- 1) Make sure the aircraft power is off.
- 2) Loosen the screws on both sides of the accessory and remove it.
- 3) Insert both ends of the protective cover into the corresponding slots.
- 1) Make sure the aircraft power is off.
- 2) Gently twist to remove the protective cover.
- 3) Align the screws and tighten them securely.
Feature-Packed
The Autel EVO 2 Pro 6K Enterprise Bundle comes packed with everything you need to perform enterprise field operations.
- SkyLink2.0 Video Transmission
- 360° Obstacle Avoidance
- Moonlight Algorithm 2.0
- Included Modular Accessories
- Centimeter-level Positioning with RTK
- ADS-B Signal Receiver
Powerful Hybrid Sensor Payload
640x512 30Hz Thermal Imaging Sensor
Equipped with 640x512 high-resolution thermal imaging camera featuring a 13mm focal length lens and 16x digital zoom, it is easy to observe distant targets. The system uses a new image processing algorithm, making thermal imaging details clearer and more discernible than competition with the similar resolution and hardware.
.8" RYYB CMOS Sensor
Equipped with a .8" RYYB CMOS sensor, featuring moonlight algorithm 2.0 that provides excellent noise suppression in limited lighting conditions, further enhancing its 50 megapixel camera to give users more details for better forensics and analysis. Detect, identify, classify subjects in low light situations and proceed with certainty.
Multiple Temperature Measurement Modes
Spot Temperature Measurement
Displays the temperature of a selected object with just a tap of the screen.
Regional Temperature Measurement
Displays the maximum, minimum, and average temperature of a selected area.
Central Temperature Measurement
Displays the temperature in the center area of the screen.
Temperature Alarm
Alerts the user when the temperature of an area reaches a predetermined threshold.
Isotherm
Detects any objects within a specified temperature range.
Image Enhancement
Allows the user to adjust the image brightness, contrast, and image details in real time.
SkyLink 2.0 Video Transmission
The EVO 2 RTK V3 Series V3 is upgraded with Autel's all new SkyLink 2.0 Video Transmission technology.
- Fly farther with HD video transmission up to 9.3 miles (15km)
- Obtain critical details with QHD video within 0.6 miles (1km)
- Support tri-band communication and can automatically frequency hop for maximum anti-interference capability.
*900MHz is only applicable for FCC countries.
42 Minutes of Flight Time
Large propellers and revised flight algorithms gives the EVO 2 Enterprise V3 the longest flight time in its category.
Extended Thermal Vents
The EVO 2 Enterprise V3 has additional thermal vents for additional heat dissipation, prolonging battery life.
Longer Carbon Fiber Arms
Carbon fiber arms and longer propellers provide additional rigidity and flight stability to the EVO 2 Enterprise platform.
360° Obstacle Avoidance
Equipped with 12 visual optical sensors, which integrates 19 sets of sensors including the main camera, ultrasonic wave, and IMU to build a 3D map of the drone and its surroundings in real time. The sensors are strategically placed to minimize blind spots on the drone so V3 can automatically stop near obstacles.
*Please refer to the manual for details on obstacle avoidance and its limitations, which may or may not work in limited lighting
ADS-B Receiver
Detects the presence of any manned aircraft nearby emitting an ADS-B signal, giving the operator enough time to take evasive measures to avoid mid-air collisions.
Mission Versatility
With an expanded selection of accessories at its disposal, the EVO 2 Enterprise V3 can evolve from a simple imaging tool to a multifunctional flight platform that can adapt to different scenarios.
Spotlight
Produces a powerful long distance aerial light when searching or shooting at night.
Loudspeaker
Enables effective on-site communication through long-distance live broadcasts and pre-recorded audio loops.
Strobe
Indicate the location of the aircraft at night to avoid air traffic collisions.
Autel Smart Controller V3
Autel's Smart Controller V3 features a 7.9-inch, 2000nits high-brightness screen that is clearly visible even under direct sunlight. SkyLink 2.0 Transmission technology guarantees long-distance operations from up to 9.3 miles (15km) away and enhances anti-interference abilities with triple band frequency hopping. The customized Android system allows for additional flexibility with 3rd party Apps and an IP43 rating ensures all weather performance.
The Autel EVO 2 Pro 6K Enterprise V3 supports multi-port HDMI real-time output to meet the requirements of projection monitoring and live streaming with Live Deck 2. The Live Deck 2 features:
• 1080P/60FPS Video Stream Capability
• Three Auto-Switch Bands
• 7.45 mile (12 km) Transmission Range
• 5-Hour Battery Life
• IP43 Resistance
The Autel EVO 2 Pro 6K Enterprise Bundle was tailored for the following commercial applications:
Public Safety - Assess threats from a safe distance, patrol an area during an investigation, or gather intelligence.
Powerline Inspection - Zip between transmission towers to quickly spot structural damage or overheating electrical elements, saving time and labor costs.
Traffic Supervision - Monitor traffic flow over a larger area and crack down on traffic violations to improve safety for everyone on the road.
Search and Rescue - Quickly locate missing persons by using automated mission modes to cover larger search areas in situations where every second counts.
Firefighting - Soar above the flames to identify hotspots, locate victims, and monitor changing conditions, reducing the risk for crew members on the ground.
Mapping - Create cost-effective 3D maps of an area using high-resolution images up to 2cm GSD* with an vertical accuracy of 1cm and a horizontal accuracy of 1.5cm.
Applications for 640T Thermal drones
|
 Wildlife Management |
 Wildlife Hunting |
 Roof Inspection |
 Line Inspection
|
 CatchSuspects |
Thermal Drones In Search and Rescue operations
Autel EVO II 640T Thermal Drone is a versatile and reliable tool for search and rescue operations. With its high-resolution thermal imaging camera, long flight time, and accurate positioning capabilities, this drone is designed to assist search and rescue teams in finding and rescuing victims in a timely and effective manner.
The high-resolution thermal imaging camera on the Autel EVO II 640T provides clear images of targets, making it easier to identify and locate the target for rescue. Additionally, the drone has the capability to store infrared images, allowing search and rescue teams to analyze and evaluate the images after the operation.、
The Autel EVO II 640T also has a long flight time, ensuring that the drone can be used for extended periods without the need for a recharge. This is especially important in search and rescue operations, where the drone may need to fly for hours in order to cover a large area.
GPS
3.The user-friendly interface on the Autel EVO II 640T makes it simple and easy for search and rescue teams to operate the drone. The intuitive controls and simple navigation features allow teams to focus on the task at hand, without having to worry about complex operations.
Finally, the Autel EVO II 640T is built to be reliable, with good stability and reliability. This is essential in search and rescue operations, where the drone must be able to perform in demanding conditions and under high stress. With its combination of features and capabilities, the Autel EVO II 640T is a valuable tool for search and rescue teams looking to enhance their operations.
Thermal Drones In Wildlife Management
In 2022, wild pigs continued to have a significant impact in several states within the United States, causing widespread damage to crops, spreading diseases, and posing a threat to native wildlife. The affected states include Texas, Florida, California, and several others in the Southeast and West regions. The population of wild pigs in the US was estimated to be between 2 to 6 million, with populations growing at an alarming rate. Wildlife management agencies and farmers were concerned about the issue, as the pigs' destructive behavior caused economic losses and ecological harm. Efforts to control the wild pig population through hunting, trapping, and other means were ongoing.
|
|
|
 Crops
|
 Pasture
|
 Livestock
|
 Horticulture
|
Why Autel EVO II Dual 640T?High-resolution imaging - The EVO II Dual 640T features a dual-camera system with a 64-megapixel sensor that provides high-resolution images and video, making it easier to identify and track wild boars.
Long flight time - With a maximum flight time of 40 minutes, the EVO II Dual 640T allows hunters to cover large areas and stay in the air longer.
Stable flight - The EVO II Dual 640T features advanced stability systems, including obstacle avoidance and advanced image stabilization technology, making it easier to fly in challenging environments.
Real-time transmission - The EVO II Dual 640T features a low-latency video transmission system that allows hunters to see what the drone is seeing in real-time, making it easier to track and identify wild boars
|
 |
Thermal Drones in Hunting
The EVO II Dual 640T is a highly advanced drone that can greatly assist hunters in their pursuits. With a dual 640T thermal camera and high-resolution imaging capabilities, hunters can locate and track game from the air. The drone's long flight time and stable flight performance also allow for extended monitoring and observation of wildlife. This cutting-edge technology can help hunters plan and execute successful hunting trips, increasing their chances of making a successful catch.
 |
Thermal Drones In Residential Roof Inspection
Inspect and document the exterior condition of shingle, tile, or slate roof structures with ease using the high-resolution visible imaging capabilities of the Autel EVO II Dual 640T drone. Utilizing unmanned aerial vehicle (UAV) technology, this drone provides a detailed view of the roof, allowing you to easily observe hail damage, wind damage, openings in the roof, cracked tiles, and much more. When water gets on the surface of the membrane, it creates a higher temperature that can be easily detected using the infrared imaging capabilities of the Autel 640T. This versatile tool makes roof inspections quicker, safer, and more efficient, delivering reliable results every time.
|
|
Thermal Drone in Industrial Inspection
Streamline your roof inspection process with the advanced technology of the Autel EVO II 640T drone. Equipped with an 8K Visual Spectrum Sensor and a 640 Radiometric Thermal Sensor, this drone enables inspectors to perform multiple roof inspections in significantly less time compared to traditional methods. The drone kit not only allows for a visual inspection of the entire building, but also utilizes thermal technology to detect hot spots.
This allows for a safe and efficient check of the structure's status, enabling you to easily identify defects, leaks, and corrosion issues without incurring the cost of additional personnel or equipment. With the Autel EVO II 640T drone, you can be confident in delivering accurate and thorough inspection results every time
-
No production shutdown Without shutting down the production, a UAV thermal analysis enables us to detect leaks, structures’ heat problems and early signs of weaknesses.
-
Safer Autel EVO II Dual 640T thermal drone enables us to detect anomalies beforehand to avoid real problems, breakdowns or accidents.
-
Faster A thermal camera can detect oil and gas leaks and directly assess reliable assets.
-
More accurate 640T thermal drrone take accurate pictures
based on different detected temperatures. -
Easier to operate EVO II Dual 640T drone teams operate with a
two-men team and one backpack carrying the intervention equipment. EVO II DUAL 640T interventions are fast, accurate and do not
require complex deployment. -
More efficiently The EVO II Dual 640T with a 40-minute flight time and a 640 x 512 thermal camera can quickly find hidden dangers that were previously invisible to the naked eye.
Thermal Drones In Line Inspections
Prevent electrical network failures and the associated consequences of blackouts or destructive fires with advanced thermodiagnostic tools. The Autel EVO II Dual 640T thermal drone, combining cutting-edge thermal imaging and unmanned aerial vehicle (UAV) technology, serves as an early warning system for potential problems.
Thermography, the technical field concerned with the non-contact measurement of temperature distribution on the surface of an object, is at the forefront of these efforts. With the ability to quickly and accurately detect thermal anomalies, the Autel 640T provides an effective solution for maintaining the safety and reliability of electrical networks. Don't let failures compromise your infrastructure, invest in the power of thermodiagnostics with the Autel EVO II Dual 640T thermal drone.
 |
 |
 |
 |
Thermal Drones in Police Use
The Autel EVO II Dual thermal drone proved to be a valuable tool for the Nevada sheriff's department when they needed to locate a suspect who had fled into the darkness. The thermal camera on the EVO II allowed the deputy, Greenhut, to search the area and eventually spot the suspect hiding behind a tree. The ability to locate the suspect with the thermal camera made it possible for backup to arrive and make the arrest. This situation highlights the importance of thermal imaging technology in law enforcement and its ability to assist in capturing suspects in low light conditions.
 |
 |
 |
 |
Deputy Greenhut was able to get eyes on the suspect and provide intel to his responding partners to advise them on the suspect’s whereabouts and whether it appeared he had any weapons. This information is very helpful to ensure a safe and effective response when encountering an unknown individual in the dark of night
Aircraft
| Weight | 1209 g (with propellers & battery) |
| Maximum Takeoff Weight | 1270 g (C2) |
| Dimensions | Folded: 230×130×108 mm Unfolded: 457×558×108 mm |
| Wheelbase | 397 mm |
| Max Rotation Speed | 9000 rpm |
| Maximum Flight Time | 38 minutes (no wind) |
| Maximum Hover Time | 33 minutes |
| Maximum Flight Distance | 22 km |
| Maximum Transmission Range | FCC: 10 km | CE: 8 km |
| Maximum Service Ceiling | 5000 m |
| Maximum Wind Resistance | Takeoff: 10.7 m/s | Cruise: 12 m/s |
| Operating Temperature | -10℃ to 40℃ |
| GNSS | GPS / Galileo / BeiDou / GLONASS |
| Internal Storage | 8GB |
Visual Camera ① (50MP)
| Sensor | 1/1.28" CMOS, 50MP |
| Lens | 85° FOV | 23mm equivalent | f/1.9 |
| ISO | 100 – 6400 | Night Mode up to 320000 |
| Shutter | 1/8000 – 8s |
| Zoom | 1–16x digital (4x lossless) |
| Max Photo Size | 8192×6144 |
| Video Resolution | 4K up to 60fps |
| Video Format | MP4 / MOV (H.264 / H.265) |
| Max Bitrate | 60 Mbps |
Visual Camera ② (12MP)
| Sensor | 1/2" CMOS, 12MP |
| Lens | 84° DFOV | 24mm equivalent | F2.8 |
| Zoom | 1–16x digital |
| Video Resolution | 4K @ 30fps |
| Photo Format | JPG / DNG |
Thermal Camera
| Sensor | Uncooled VOx Microbolometer |
| Resolution | 640×512 |
| Focal Length | 13mm |
| Temperature Range | -20℃ to 550℃ |
| Accuracy | ±3℃ or ±3% |
| Zoom | 1–16x |
| Video | 640×512 @25fps (H.264 / H.265) |
Gimbal
| Stabilization | 3-axis mechanical |
| Pitch Range | -135° to +45° |
| Yaw Range | -100° to +100° |
| Max Control Speed | 300°/s |
| Angular Vibration | 0.005° |
Autel Smart Controller V3
| Display | 7.9" TFT LCD | 2048×1536 | 2000 nits |
| OS | Android 11 |
| Internal Storage | 128GB |
| Video Output | HDMI 1080P@60fps |
| Transmission Distance | FCC: 15 km | CE: 8 km |
| Battery | 5800mAh | 67Wh | 2.5–4h runtime |
| Protection Rating | IP43 |
Smart Battery
| Model | XE3_7100_1155 |
| Capacity | 7100 mAh |
| Energy | 82 Wh |
| Voltage | 11.55 V |
| Weight | 365 g |
| Charging Time | Approx. 90 minutes |
| Operating Temperature | 0℃ to 45℃ |
