PRIDE SOLO 300 NEO 6.5" 300W RMS 4-Ohms Car Audio Midrange Speakers (Pair)
BRAND NEW
PRIDE AUDIO SOLO 300 NEO 6.5
6.5-inch 300 Watts RMS 4-Ohms Car Audio Midrange Speakers (Pair)
Key Features:
- 6.5" midrange speaker
- 300W RMS / 4 Ohm
- 96.5 dB sensitivity (estimated)
- Frequency Range: 160 Hz – 10,000 Hz (recommended)
- 1.75″ (44.5 mm) high-temp voice coil on Kapton former
- Neodymium motor for high power-to-weight ratio
- Mounting depth: 63 mm (2.48″)
- Cutout diameter: 152 mm (5.98″)
- 8-hole aluminum basket
- Lightweight design for SPL systems
Specifications:
- Nominal Diameter: 6.5" / 165 mm
- Nominal Impedance: 4 Ohms
- RMS Power Handling: 300W
- MAX Power Handling: 600W (estimated)
- Sensitivity (1w/1m): 100.2 dB (estimated)
- Frequency Response: 160Hz – 10,000Hz (recommended)
- Recommended HI Pass Crossover: 160 Hz depending on the power
Motor Features:
- Voice Coil Diameter: 1.75" / 44.5 mm
- Voice Coil Former Material: Kapton
- Winding Material: CCAW (assumed)
- Cone Material: Pressed Paper
- Dust Cap Material: Paper
- Surround Material: Nomex Cloth (assumed)
- Frame Material: Aluminum
- Basket Color/Finish: Black
- Magnetic Material: Neodymium
- Magnetic Core Material: Electrical Steel
- Equivalent Volume (Vas): 2.9 L / 0.1271 ft³
- Free Air Resonance (Fs): 162 Hz
- Mechanical Factor (Qms): 1.71
- Electrical Factor (Qes): 0.19
- Total Factor (Qts): 0.16
- Mechanical Mass (Mms): 11.2 g
- Mechanical Compliance (CMS): 0.072 mm/N
- BL Factor (BL): 11.2 p
- Cone Area (Sd): 162 cm²
- DC Resistance (Re): 3 Ohms
Measurements:
- Overall Diameter: 6.83" / 173.5 mm
- Diameter of the Mounting Hole: 5.98" / 152 mm
- Overall Depth: 2.48" / 63 mm
- Mounting Flange Height: 0.65" / 16.5 mm
- Box Contents: Pair of speakers
