Product Details

Descriptions:

1. Overview:
Comply with DMX512 international standard protocol
Built in change mode, you can adjust by dialing code
DMX512 address code can be set via DIP
3 relay outputs
Working voltage: DC12V-24V
We Accetpt OEM services
2. Basic parameters:
Dimensions: 120MM * 55MM * 25MM (L * W * H)
Working temperature: -20 ℃ - 60 ℃
Supply voltage: DC12V-24V
Relay load: 5A per channel
Weight: 100g

3. Features:
DIP10 function key (FUN).
DIP10 (FUN) is OFF, as DMX512 mode, receive standard DMX512 signal.
Occupies three address code, (R, G, B for each channel), DIP1-DIP9 address code setting.
When less than 127 DMX512 data relay off
DMX512 data is greater than 127 when the relay is closed

DIP10 (FUN) is ON, the built-in change mode and does not receive standard DMX512 signal.
DIP1-DIP9 to invoke the built-in effects settings.
Package included:
1-5PCS 5A 3 Channel DMX512 Controlled Relay Switch DIY Kit Converter DMX Dimmer Relay
