Automatic screw supply machine features:
1,the widest range of usage.
Length can be made of M0.8 to M5 (< 20 mm) between any specifications, the reasonable adjustment, BuKa material oh.
2,can use special screws.
Can use ordinary screw, flat head screws with washers screw, tapping screw and so on many kinds of screws, consult the seller don't understand.
3,orbit size can be adjusted.
Orbital size adjustment easy, cooperate with screw size, whether in cm or inch specifications, are able to operate freely.
4,to reduce inventory cost reduction.
A machine can adjust out of a variety of specifications using screw, the user can reduce the cost of equipment procurement.
5,size adjustable vibration.
Seismic distance is small, strong vibration, screw arrived at the front end point, not running forward and obvious effect to the speed of the screw and the production speed.
6,the humanized management for projects to be more.
Send material and the driving mode of vibration independence, are free to set the ideal stop time, will not cause mutual interference and influence the normal function. Screw roller rolling blanking you then, arriving at the front of the vibration time, screw speed in orbit, performed with single-chip microcomputer control, time to cooperate with production line homework. Machine adopts 110-240 - v AC voltage input, dc 12 v power supply output voltage stability, provide the correct voltage, makes the machine can be used anywhere in the world and it works, will not be affected by the input voltage is too high or low.
Automatic screw supply machine parameters:
1, the product model: KLD - V5
2, exterior size: 125 w * 180h * 150 DMM
3, weight: 3.5kg
4, communication power supply: AC 110-240v.
5, screw length range: less than or equal to 20 mm
6, orbital adjustable range: 0.8 MM to 5.0 MM
7, thread shape: M, tapping screw
