The key reason to Choose LAUNCH CRT5011E TPMS Diagnsotic Tool

• 3.5 inch inch color screen


• Activate all 315/433MHz tire sensor

• Read, copy, write Sensor ID quickly

• Progarm up to 8 sensors

•

•

• Tire pressure fault diagnosis, including read DTC, clear DTC, etc.

• Built-in tire pressure learning instruction makes operation more easy

• Cover 98% global vehicles with tire pressure system

• Offer lifetime free update Online

•

Sensor activation

• LAUNCH X431 TSGUN can quickly activate the ID, wheel pressure, sensor frequency, tire temperature and battery status of the live sensor.

Sensor progarmming

The user can use this function to progarm the sensor data to a blank LAUNCH sensor to replace the sensor with insufficient power and not working properly.

• Provides three sensor progarmming methods: automatic, manual and copy by activation.

• The user can use this function to progarm the sensor data to a blank LAUNCH sensor to replace the sensor with insufficient power and not working properly.

• Provides three sensor progarmming methods: automatic, manual and copy by activation.
•

• Automatic: When the original sensor ID cannot be obtained, this function can be used to progarm the LAUNCH sensor according to the ID randomly created by the test vehicle.

•

• Manual:The original sensor ID can be obtained, and this function can be used to manually enter the ID or create it at will.


• Copy by activation: By first activating the original sensor data, and then copying the activated sensor data into the LAUNCH sensor. Before using this method, the original sensor data must be activated.

TPMS Learning

• The user can use this function to write the newly progarmmed sensor ID into the vehicle E.CU for sensor identification. Only when the newly progarmmed sensor ID is different from the original sensor ID stored in the vehicle E.CU, the re-learning operation is required.

• A total of three sensor learning methods are provided: static learning, self-learning and OBD re-learning

• Static learning
  Static learning needs to put the vehicle in "learning mode", and then follow the learning steps prompted on the screen.

• Self-study
  For some vehicles, the learning function can be completed by driving the vehicle self-learning.

• OBD re-learning
  This function allows the diagnostic equipment to directly write the sensor ID to the TPMS module.
  To perform the OBD re-learning function, first use the tire pressure tool to activate all four tire sensors. Then use the diagnostic equipment and its attached diagnostic connector, and follow the on-screen instructions to complete the re-learning operation.

OBD2 Diagnosis

• Check for DTCs, isolate the cause of the illuminated Malfunction Indicator Lamp (MIL), check monitor status prior to emissions certification testing, verify repairs, and perform a number of other services that are emission-related.

• Read dynamic data streams and MIL

• Read readiness status

• Freeze frame data

• Read DTCs

• Clear DTCs

• O2 sensor test

• On-board monitor test

• Read vehicle information

CRT5011E Car Supported List:

• For ABARTH,for ACURA ,for ALFA ROMEO, for ASTON-MARTIN ,for AUDI , for ALPINA , for BAIC, for BAOJUN, for BENTLEY,for BMW, for BORGWARD, for BUGATTI,for BUICK, for BYD
• For CADILLAC, for CHANGAN, for CHERY, for CHEVROLET, for CHRYSLER, for CITROEN, for CMC, for DACIA, for DAEWOO, for DFM, for DODGE, for FAW, for FERRARI, for GEELY, for GMC, for GREAT WALL, for HAVAL, for HAIMA, for HOLDEN, for HONDA, for HSV, for HUMMER, for HYUNDAI,
• For INFINITI, for ISUZU, for JAC, for JAGUAR, for JEEP, for KIA, for LADA , for LAM BORGH-INI, for LANCIA, for LANDROVER, for LEXUS, for LIFAN, for LINCOLN, for LOTUS, for LUXGEN, for MAHINDRA, for MAN, for MASERATI, for MAYBACH, for MAXUS, for MAZDA, for MCLAREN, for MERCEDES, for MG, for MINI, for MITSUBISHI, for NISSAN , for OPEL , for PAGANI, for PEUGEOT
• For PORSCHE, for QOROS, for RENAULT,for ROLLSROYCE, for SAAB, for SCION, for SEAT, for SKODA, for SMART, for SSANGYONG, for SUBARU, for SUZUKI, for SGMW, for TESLA, for SMART, for SSANGYONG, for SUBARU, TOYOTA, for TRAUM, for VAUXHALL, for VOLKSWA-GEN , for VOLVO, for ZOTYE,for FIAT, for FORD, for FOTON, for CHRYSLER, for GMC

• For DFM, for CADILLAC, for CHERY, for CHEVROLET , for DODGE,for FAW, for FERRARI, for JAC ,for JAGURE

Packing List:

1pc x LAUNCH CRT5011E host
