Hollyland Pyro 5 Wireless Transceiving Monitor with Dual Band Transmission
Hollyland Pyro 5 Wireless Transceiving Monitor with Dual Band Transmission
- Dual-band transmission
- Broadcast Mode
- Direct camera control
- Proxy recording
- Multi-cam switching
- Lock Pairing
- Auto Frequency Hopping
- Smart channel selection
- 3D LUT support
- HDMI and SDI loopout
- Rugged design
- RTMP streaming
- Pyro 5 Wireless Transceiving Monitor
- Tempered Glass Screen Protector
- 2 x Easy-Install Short Antenna
- USB-C OTG Adapter
- Quick Guide
- Packing List Card
- Warranty Card
Pyro 5 is a 5.5-inch wireless monitor designed for do-it-all performance. With dual-band transmission, 4-way monitoring via Broadcast Mode, direct camera control, smart channel selection, and a 1500-nit daylight-viewable screen, it combines multiple functions into one compact tool. Proxy recording, real-time overlays, and RTMP live streaming make Pyro 5 more than just a monitor-it's your multi-tasking hub on set, built to simplify and speed up every step of production.
Shoot.Sync.Share.
Pyro 5 is a 5.5-inch wireless monitor designed for flexible on-set collaboration. Powered by cutting-edge Wi-Fi-Broadcast technology, it allows one transmitter to connect with up to four receivers while maintaining stable, real-time video transmission.
Broadcast Mode
In Broadcast Mode, one transmitter connects to up to four receivers with camera views switching and auto frequency hopping. Ideal for multi-cam setups, it delivers stable performance at up to 200m line-of-sight or 100m back-to-back. Pyro 5 still supports one-to-four transmission even when Broadcast Mode is off. At the same time, it offers a more extended range, up to 400m line-of-sight and 150m back-to-back.
Dual-Band Stronger Signal. Smoother Feeds.
Built with a dual-band 2.4G/5G transmission system, Pyro 5 automatically adapts to changing environments— delivering robust, interference-resistant video even in signal-heavy locations.
Direct Camera Control. Just a Tap Away.
With the 5.5-inch touchscreen, Pyro 5 enables direct adjustments to shutter speed, aperture, focus, focus mode, white balance, and ISO, offering dynamic control over your camera's settings. It enables direct adjustments to shutter speed, aperture, focus, focus mode. white balance, and ISO, offering dynamic control over your camera's settings.
More Than a Monitor. Efficient Proxy Recording.
Proxy files can be recorded directly to an SD card or USB drive while monitoring in real-time. Automatically organized into folders, proxy files are ready to review or cut. The Proxy files now include timecode, perfectly synced with your camera for easier, more accurate editing.
Multi-Cam Switching.
Pyro 5 supports switching between camera groups, keeping up with fast-paced live productions.
Lock Pairing
When multiple Pyro systems are in use, Lock Pairing ensures each receiver stays securely connected to its original transmitter-no signal mix-ups.
Auto Frequency Hopping
Pyro 5 is equipped with Auto Frequency Hopping technology, which constantly scans and monitors the strength of the signal and interference across various frequency ranges to find the best wireless channel to use, resulting in a more reliable connection.
Smart Channel Selection
At startup, the system automatically scans and locks onto the optimal frequency channel.
Channels can also be manually scanned and switched via the receiver, with visual signal strength indicators for each frequency.
3D LUT, HDMI and SDI Ports
Pyro 5 comes with 5 built-in LUTs and supports custom LUT import. With both HDMI and SDI loopout, it fits seamlessly into a wide range of production setups.
Built to Feel Good. Made to Last.
A dual-injection shell keeps the device light in hand and strong enough to handle the roughest shoots. The Easy-install antennas make setup, transport, and storage faster and easier than ever. Every detail is designed for the field—from the rugged build to the streamlined setup.
RTMP Streaming
Stream directly to Zoom, YouTube Live, TikTok, and more with the HollyView App and RTMP support. Just connect a 4G LTE WiFi modem, enter your stream key, and you're live—no extra setup needed.
Specifications
Input Port
- Transmitter Mode: HDMI 1.4b + 3G SDI
- Rocelver Mode: /
Output Port
- Transmitter Mode: Loop-Out HDMI 1.4b
- Receiver Mode: HDMI 1.4b
Audio-Video Parameters
- Transmitter Mode: Color Depth Capability
- Transmitter Mode: Input Audio Format
- Transmitter Mode: Output Audio Format
- Receiver Mode: HDMI Input: YUV422/YUV444 8BIT
- Receiver Mode: HDMI 1.4b 8-Channel
Antenna
- SMA Male
Power Input
- DC Input (2.0mm coro socket)
Headphone Jack
- 3.5mm
Upgrade Port
- USB-C (USB 2.0 CTG) / SD Card Slot
Screen Size
- 5.5in Touchscreen
Screen Resolution
- 1920x1080 Pixels
Color Gamut
- Rec.709
Aspect Ratio
- 16: 9
Screen Brightness
- 1,500 nits
Contrast Ratio
- 1000-1
Power Input Voltage
- NPF: 6V-16V
- DC-in: 10-18V DC
Video Processing Technology
- Transmitter Mode: Vidco Bitrate
- Transmitter Mode: Video Encoding Format
- Receiver Mode: Maximum 12 Mbps
- Receiver Mode: H.264
Power Consumption
- Transmitter <14W
- Receiver Mode: <16.5W
Net Weigh
- 538g (1902)
Dimensions
- (LxWx): 180x127x45.8mm
Operating Frequency
- 5.150-5.250GHz
- 2412-2.484GH2
- 5.250-5.350GHz
- 5.470-5.600GHz
- 5.600-5.725GHz
- 5.725-5.850GHz
Transmit Power
- Transmitter Mode: < 23dBm
Receiver Sensitivity
- Receiver Mode: Unicast: -85dBm; Broadcast: -80dBm
Transmission Latency
- =60ms (Tested in a laboratory environment with 1080P60 signal transmission)
Bandwidth
- Unicast: 20 MHz Broadcast: 40 MHz
Operating Temperature
- -10°C - 45°C
Storage Temperature
- -40°C - 60°C
