Input voltage

Regular models 140V-260/300V, ultra low voltage models 90-260/300V

Output voltage

3KVA, 220V

Voltage regulation accuracy

220V±3%, 11V±6%

Frequency

50Hz/60Hz

Overvoltage protection value

Output voltage 260V±4V

Undervoltage protection value

Output voltage 186V±4V, regularly not set undervoltage protection

Load power factor

0.8

Adjust time

When the voltage change by10%﹤1S

Waveform distortion

No additional waveform distortion

Dielectric strength

1500V/1min

Insulation resistance

Single phase ﹥5MΩ

Insulation class

Class E

Working environment

Temperature :-10℃ to +40℃, Humidity: ﹤95%

Effectiveness

﹥95%

Temperature rise

﹤60℃
