HJD3125

HJD3125 is a Cutler Hammer molded case circuit breaker with 125 ampere rating and 3 poles designed for 600 volt applications.HJD3125 features a Series C J-frame design with thermal magnetic protection and interchangeable trip unit offering long-time and instantaneous trip functions. It has a high interrupting capacity of 65kA at 480V and supports feed-thru connections with line and load side lug terminals.

Key Specifications
• Amperage: 125A
• Voltage: 600V AC, 250V DC
• Poles: 3
• Frame Type: J Frame, Series C
• Trip Unit: Thermal Magnetic, Interchangeable (Long-Time and Instantaneous)
• Interrupt Rating: 65kA at 480V
• Mounting Type: Fixed
• Connection: Feed-Thru with line & load side lugs
• Dimensions: 4.13" x 4.13" x 4.06"
• Weight: 12.5 lbs
• Certifications: Meets industry standards for molded case circuit breakers
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Specifications

• Part Number: HJD3125
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : HJD
• Voltage : 600
• Amperage : 125
• Phase : 3
• Poles : 3
• AIC rating : 65kA@480V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous
• Frame Size : J Frame
• Protection : Thermal Magnetic



Product Data

• UPC : 786679319048
• GTIN : 00786679319048
• Country of Origin : Dominican Republic
• Dimensions : 4.06 in x 4.13 in x 4.13 in (Length/Depth x Height x Width)
• Weight : 12.5
• Certification : UL Listed
