NON-4

NON-4 is a 4 Amp, 250 Volt AC, Class K5 one-time general purpose fuse from Eaton Bussmann.This fuse features a 250 VAC voltage rating and a 125 VDC rating with a high interrupting rating of 50,000 AIC RMS at 250 VAC and 50,000 AIC at 125 VDC. It is designed for general purpose circuit protection with a physical size of 0.56 inches by 2 inches. The NON-4 fuse meets UL Class K5 standards (Std. 248-9) and is CSA certified (Class 1421-01). It is a non-current-limiting, one-time fuse suitable for control circuits and other applications requiring reliable protection.

Key Specifications
• Amperage: 4 Amps
• Voltage Rating: 250 VAC / 125 VDC
• Fuse Type: One-Time, General Purpose
• Class: K5
• Interrupting Rating: 50,000 AIC RMS @ 250 VAC, 50,000 AIC @ 125 VDC
• Physical Size: 0.56" x 2"
• Standards: UL Listed, CSA Certified
• Manufacturer: Eaton Bussmann
• Mounting Type: Fuse holder or block (standard size)
• Poles: Single Pole
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Specifications

• Part Number: NON-4
• Manufacturer : Eaton
• Brand : Bussmann
• Category : Fuse
• Item Subcategory : Low Voltage Fuse
• Voltage : 250
• Amperage : 4
• AIC rating : 50kA@250V
• Diameter : 1.06
• Class Rating : K5
• Barrels : 1



Product Data

• UPC : 051712300049
• GTIN : 00051712300049
• Country of Origin : Mexico
• Dimensions : 0.56 in x 2 in x 0.56 in (Length/Depth x Height x Width)
• Weight : 0.35
• Certification : CE, UL Listed, Guide JDDZ, File E4274, STD 248-9, CSA Certified Class 1421-01, File 53787
