Motherboard chip:
Integrated chip: sound card/network card
Main chipset: Intel Z87
Chipset description: using Intel Z87 chipset
Display chip: CPU built-in display chip (requires CPU support)
Audio chip: integration Realtek ALC1150 8-channel sound effect chip
Network card chip: onboard Intel I217V Gigabit network card
Processor specifications:
CPU type: Core i7/i5/i3
CPU slot: LGA 1150
CPU description: supports Intel 22nm processors
Memory specifications:
Memory type: 4 × DDR3 DIMM
Maximum memory capacity: 32GB
Memory description: supports dual channel DDR3 1866/1600/1333MHz memory
Storage Expansion:
PCI-E standard: PCI-E 3.0
PCI-E slot: 3 × PCI-E X16 graphics card slot, 3 × PCI-E X1 slot
Storage Interface: 10 × SATA III interface
I/O interface:
USB interface: 8 × USB2.0 interface (4 built-in+4 backplane), 6 × USB3.0 interface (2 built-in+4 backplane)
Video interface: 1 × Display Port interface, 1 × HDMI interface
1x 8-pin power interface and 1x 24-pin power interface
Other interfaces: 1 × RJ45 network interface, 1 × Fiber optic interface, audio interface
Plate type:
Main board type: ATX board type
External dimensions: 30.5 × 24.4cm
Other parameters:
Multi graphics card technology: supports AMD Quad CrossFireX dual card quad core crossfire technology
Overfrequency function: support
RAID function: supports RAID 0, 1, 5, 10
Integrated chip: sound card/network card
Main chipset: Intel Z87
Chipset description: using Intel Z87 chipset
Display chip: CPU built-in display chip (requires CPU support)
Audio chip: integration Realtek ALC1150 8-channel sound effect chip
Network card chip: onboard Intel I217V Gigabit network card
Processor specifications:
CPU type: Core i7/i5/i3
CPU slot: LGA 1150
CPU description: supports Intel 22nm processors
Memory specifications:
Memory type: 4 × DDR3 DIMM
Maximum memory capacity: 32GB
Memory description: supports dual channel DDR3 1866/1600/1333MHz memory
Storage Expansion:
PCI-E standard: PCI-E 3.0
PCI-E slot: 3 × PCI-E X16 graphics card slot, 3 × PCI-E X1 slot
Storage Interface: 10 × SATA III interface
I/O interface:
USB interface: 8 × USB2.0 interface (4 built-in+4 backplane), 6 × USB3.0 interface (2 built-in+4 backplane)
Video interface: 1 × Display Port interface, 1 × HDMI interface
1x 8-pin power interface and 1x 24-pin power interface
Other interfaces: 1 × RJ45 network interface, 1 × Fiber optic interface, audio interface
Plate type:
Main board type: ATX board type
External dimensions: 30.5 × 24.4cm
Other parameters:
Multi graphics card technology: supports AMD Quad CrossFireX dual card quad core crossfire technology
Overfrequency function: support
RAID function: supports RAID 0, 1, 5, 10
