Rubber Coated Neodymium Magnets Ø 22 mm - Ø 88 mm screwed bush, rubber jacket - holds 5,8 kg - 55 kg

Magnet assembly of NdFeB, rubber coat black, with screwed bush

These systems are used on delicate surfaces and the slip resistance is improved thanks to rubber coating

"Over 300,000 satisfied customers"

Rubber Coated Neodymium Magnets Ø 22 mm - Ø 88 mm screwed bush, rubber jacket - holds 5,8 kg - 55 kg    Rubber Coated Neodymium Magnets Ø 22 mm - Ø 88 mm screwed bush, rubber jacket - holds 5,8 kg - 55 kg

This rubber coated neodymium mounting magnet measures 22 mm - 88 mm. It has a center hole with an female thread. The Santoprene rubber coating protects surfaces. This rare earth magnet has a pull force adhesive force 5.8 kg - 55 kg.

The multiple pole design of these rubber coated Neodymium (NdFeB) pot magnets ensures a dense shallow magnetic field on the holding surface. This allows for excellent holding onto thin, lacquered car body metal. The sideways displacement (sheer forces) are extremely good due to the suction effect of the rubber surface. Maximum recommended operating temperature is 60 degrees Celsius.

These rubber coated Neodymium (NdFeB) pot magnets are especially suitable for magnetically fixing objects such as advertising displays or safety blinkers onto car roofs (the metal work must have a mild steel content - aluminium or carbon fibre surfaces will not work). The rubber coated Neodymium (NdFeB) pot magnets are also suitable for fixing signs, plates, temporary lightings and sample parts scratch-free onto highly polished chrome-plated or painted mild steel (ferrous) surfaces.

The rubber coating also provide a good level of corrosion protection in humid conditions. Because of their high performance, slide resisting properties and paint work protection ability, these rubber coated Neodymium (NdFeB) pot magnets are sometimes also known as Boutique Magnets.

Product Information

Application:

Holding magnet for workshops, laboratories, hobbies, fixture construction or tool making. Especially suitable for sensitive surfaces. Anti-slip rubber coating

Details:

  Article number D mm d mm H mm L mm Thread M Force* N Shear force* N Weight g Temperature °C
  1200 12 8 7 14.5 M4 13 5 6 60
  1200 18 8 6 11.5 M4 37 13 8.7 60
  1200 22 8 6 11.5 M4 58 18 13 60
  1200 31 8 6 11.5 M4 89 25 22 60
  1200 31 8 6 11.5 M4 89 35 23 60
  1200 43 8 6 10.5 M4 100 38 30 60
  1200 43 8 6 10.5 M5 100 38 31 60
  1200 57 10 7.6 14.5 M5 200 78 82 80
  1200 66 10 8.5 15 M5 250 85 105 80
  1200 88 12 8.5 17 M8 550 140 192 80

Characteristics

Magnet force

The forces have been determined at room temperature on a plate in polished steel (S235JR according to DIN 10 025) with a thickness of 10 mm (1kg ~ 10N). A maximum deviation of -10% compared to the specified value is possible in exceptional cases. Value is exceeded in general. Depending on the type of application (installation situation, temperatures, counter anchor etc.) the forces can be influenced enormously.

Classy look and high-quality material

Thanks to the elegant look of our magnet system neodymium rubberized magnets, they can be placed in a clearly visible position.

ROHS Policy

This article complies with the European RoHS directive (2002/95/EG - RoHS - Restriction of Hazardous Substances) for the restriction of the use of certain hazardous substances in electrical and electronic equipment. Corresponds to the European RoHS directive, is PVC and plasticizer-free and REACH-compliant - classified according to the German flame retardant standard DIN 4102 / B1
