Product Information

Hastings Piston Rings Cast STD suits Holden Isuzu 4ZD1 Jackaroo Rodeo

Item Specifics
SKU: 4603
Returns: 30 Days
Ships From: Melbourne

Description

Hastings Piston Rings Cast STD suits Holden Petrol Isuzu 4ZD1 see list below for supported models and engines

STD 020 040 1.5mm/1.5mm/4mm

Specifications

Bore Size89.30
OversizeSTD
1st Ring1.5
2nd Ring1.5
3rd Ring4

Variations for this Engine

These are the different Variations for the Holden 4ZD1 4 Cylinder Petrol Engine. Please check carefully you have selected the right part for your vehicle.

Hastings (4603) STD Piston Rings Cast STD 020 040
1.5mm/1.5mm/4mm
Hastings (4603020) +020 Piston Rings Cast STD 020 040
1.5mm/1.5mm/4mm
Hastings (4603040) +040 Piston Rings Cast STD 020 040
1.5mm/1.5mm/4mm

Suitable For

Holden
Jackaroo UBS16 4ZD1
Rodeo KB 4ZD1
Rodeo TF 4ZD1

Other Parts for this Engine

These are the different parts available for the Holden 4ZD1 4 Cylinder Petrol Engine

Cam Change Gaskets
Camshafts
Chassis and Driveline
Mackay A2531 Engine Mount Bush Engine mount front of engine left hand side
Suits Rodeo KB 2WD models
Conrod Bearings
Taiho (R172A1 0.75) Set of 4 +030 Conrod Bearings Set STD 010 020 030 040 060
Shaft 48.925/48.940mm 1.9262/1.9268¨
Tunnel 51.987/52.000mm 2.0467/2.0472¨
Taiho (R172A1 STD) Set of 4 STD Conrod Bearings Set STD 010 020 030 040 060
Shaft 48.925/48.940mm 1.9262/1.9268¨
Tunnel 51.987/52.000mm 2.0467/2.0472¨
Conversion Gasket Sets
Cooling
Cylinder Heads
Exhaust Gaskets
Filters
K&N HP-1004 Oil Filter Performance oil filter (87mm Dia.)
K&N PS-1004 Oil Filter Oil filter (87mm Dia.)
Full Gasket Sets
Head Gaskets
Hose and Fittings
Inlet Manifold Gasket
Main Bearings
King Engine Bearings (MB5559AM +010) Main Bearings STD 010 020 030
Shaft 55.919/55.932mm 2.2015/2.2020¨
Tunnel 59.980/60.000mm 2.3614/2.3622¨
King Engine Bearings (MB5559AM +020) Main Bearings STD 010 020 030
Shaft 55.919/55.932mm 2.2015/2.2020¨
Tunnel 59.980/60.000mm 2.3614/2.3622¨
King Engine Bearings (MB5559AM +030) Main Bearings STD 010 020 030
Shaft 55.919/55.932mm 2.2015/2.2020¨
Tunnel 59.980/60.000mm 2.3614/2.3622¨
King Engine Bearings (MB5559AM STD) Main Bearings STD 010 020 030
Shaft 55.919/55.932mm 2.2015/2.2020¨
Tunnel 59.980/60.000mm 2.3614/2.3622¨
Manifold Gaskets
Misc Gaskets
Miscellaneous
8 x Nason VK1013 Valve collet Suits 8mm Stem, 1 Square Bead
Nason VK1013 Valve collet Suits 8mm Stem, 1 Square Bead
Piston and Rings
Piston Rings Cast
Piston Rings Chrome
Pistons
Endurotec (PIS4ZD140002E) STD Pistons Set Of 4 STD 020 040 (set of 4) Rings not included
Use RS1663 piston rings
Compression height 39mm -5.2mm
Endurotec (PIS4ZD140202E) +020 Pistons Set Of 4 STD 020 040 (set of 4) Rings not included
Use RS1663 piston rings
Compression height 39mm -5.2mm
Endurotec (PIS4ZD140402E) +040 Pistons Set Of 4 STD 020 040 (set of 4) Rings not included
Use RS1663 piston rings
Compression height 39mm -5.2mm
Hypatec (PIS4ZD140402H) +040 Pistons Set Of 4 STD 020 040 (set of 4) Rings not included
Use RS1663 piston rings
Down .020" from std.
Compression height 38.5mm -5.2mm
Rear Main Seals
Durapro (GSNJ322D) Crankshaft Seal Rear ID 95mm x OD 118mm x depth 10mm
Sump Gasket Sets
Thrust Washers
Timing Cover Seals
Durapro (GSNJ323D) Crankshaft Seal Front ID 40mm x OD 56mm x depth 7mm
Durapro (GSNJ454D) Camshaft Seal Camshaft seal
ID 30mm x OD 45mm x depth 8mm
Durapro (GSSK039D) Timing Belt Seal Kit Timing belt oil seal kit
Timing Gasket Sets
Durapro (GSNJ144D) Oil Seal Oil pump seal
ID 24mm x O D40mm x depth 7.5mm
Timing Kits
Valve Cover Gaskets
Valve Guides
JCMC (VGIS-21/23/28-E) Valve Guide Exhaust (cast iron)
OD 12mm x ID 8mm x length 55.1mm
JCMC (VGIS-69-Z) Valve Guide Inlet (cast iron)
OD 12mm x ID 8mm x length 46mm
Valve Regrind Gasket Set (VRS)
Valve Spring Retainers
Valve Springs
Valve Stem Seals
Valves-Exhaust
JCMC (EVIS22/23-E (SS) Exhaust Valve Stellite faced
Head 35.9mm x length 109.8mm x stem 8mm
JCMC (EVIS22/23-E) Exhaust Valve Head 35.9mm x length 109.8mm x stem 8mm
Valves-Inlet
Water Pumps
