Murrelektronik 7000-18021-2260300 MSUD Valve Plug A 18mm Cable 24V LED 3M
Description
MSUD
Form A (18 mm)
24 V AC ±20% / DC ±25%
LED and suppression
Bridged PE
Further cable lengths on request.
Plastic housings with good resistance against chemicals and oils.
The resistance to aggressive media should be individually tested for your application. Further details on request.
Form A (18 mm)
24 V AC ±20% / DC ±25%
LED and suppression
Bridged PE
Further cable lengths on request.
Plastic housings with good resistance against chemicals and oils.
The resistance to aggressive media should be individually tested for your application. Further details on request.
Technical Data
| Cable length | 3,00 m |
|---|
Side 1-1
| Family construction form | Valve connector form A |
|---|---|
| No. of poles | 4 |
| Gender | female |
| Mounting method | inserted, screwed |
| Threaded hole | M3x31 |
| Tightening torque | 0,4 Nm |
| Material | PBT |
| Degree of protection (EN IEC 60529) | IP67 |
Electrical data
| Drop-out delay time max. | 20 ms |
|---|
Electrical data | Supply
| Operating voltage AC | 24 V |
|---|---|
| Operating voltage AC min. | 19,2 V |
| Operating voltage AC max. | 28,8 V |
| Operating voltage DC | 24 V |
| Operating voltage DC min. | 18 V |
| Operating voltage DC max. | 30 V |
| Current operating per contact max. | 4 A |
| Cut-off peak voltage max. | 55 V |
| Current consumption max. | 15 mA |
Diagnostics
| Status indication LED | yellow |
|---|
Installation | Connection
| Mounting set | M3x31 |
|---|
Device protection | Electrical
| Additional condition protection degree | inserted, screwed |
|---|---|
| Pollution Degree | 3 |
| Additional suppressor | Diode, Z-diode |
| Rated surge voltage | 0,8 kV |
| Material group (IEC 60664-1) | I |
Mechanical data | Material data
| Color housing | black |
|---|---|
| Screw connection | Steel |
| Coating of fitting | galvanized |
| Locking material | Steel |
| Coating locking | galvanized |
| Gasket | PUR |
Mechanical data | Mounting data
| Mounting method | inserted, screwed |
|---|
Environmental characteristics | Climatic
| Operating temperature min. | -25 °C |
|---|---|
| Operating temperature max. | 85 °C |
| Additional condition temperature range | depending on cable quality |
Important installation notes
| Note on bending radius | Attention: Observe the permissible bending radii when laying cables, as the IP protection class can be endangered by excessive bending forces. |
|---|---|
| Note on strain relief | Protect the connectors by suitable measures from mechanical loads, e.g. by the usage of cable ties. |
Cable data
General data | Cable-1
| Cable identification | 226 |
|---|---|
| Cable Type | 2 |
| Cable weigth | 50,3 g/m |
| UL AWM Style | 20549 / 1731 |
Structure | Cable-1
| Stranding | 1 × 3 wires stranded |
|---|---|
| Wire arrangement | BK 1, BK 2, GNYE |
Wire data | Cable-1
| Material wire insulation | PVC |
|---|---|
| Amount wires | 3 |
| Outer diameter insulation | 1.8 mm ± 0.1 mm |
| Conductor crosssection (wire) | 0,75 mm² |
| Material conductor wire | Stranded copper wire, bare |
| Core construction (wire) | 42 × 0.15 mm |
| Material properties wire insulation | good machinability |
| Ingredient freeness wire insulation | lead-free, cadmium-free, CFC-free, silicone-free |
Jacket data | Cable-1
| Material jacket | PUR |
|---|---|
| Outer-diameter (jacket) | 5.9 mm ± 5 % |
| Jacket Color | gray / RAL 7040 |
| Material inner jacket | PVC |
| Color (inner jacket) | gray |
| Freedom from ingredients (jacket) | lead-free, cadmium-free, CFC-free, silicone-free |
| Material property (jacket) | abrasion-resistant, low adhesion, good machinability, matte |
Electrical data | Cable-1
| Conductor resistance (wire) | 26 Ω/km @ 20 °C |
|---|---|
| Nominal voltage max. | 300 V |
| Withstand voltage (wire - wire) | 2 kV @ 60 s |
| Withstand voltage (wire - jacket) | 2 kV @ 60 s |
| Current load capacity max. (wire) | 12 A |
| Current load capacity (standard) | to DIN VDE 0298-4 |
Temperature range | Cable-1
| Operating temperature (static) | -30 °C … 80 °C |
|---|---|
| Operating temperature (dynamic) | -5 °C … 80 °C |
Resistances | Cable-1
| Oil resistance | good |
|---|---|
| Chemical resistance | good |
| Other resistances | good resistance to gasoline, resistant to hydrolysis, resistant to microbes |
| Notes | application-related testing |
Installation | Cable-1
| Bending radius (fixed) | 10 × Outer diameter |
|---|---|
| Bending radius (dynamic) | 15 × Outer diameter |
| No. of bending cycles (C-track) | 2 Mio. @ 25 °C |
| Traversing distance (C-track) | 5 m @ 25 °C |
| Travel speed (C-track) | 3.3 m/s @ 25 °C |
| Acceleration (C-track) | 5 m/s² @ 25 °C |
