Digital Rotating Viscometer for Measuring Coatings, Paints, and Inks; Liquid Pointer Viscometer

NDJ‑1S (Color Screen Model)

- Measurement Range: 1–70,000 mPa·s

- Rotor Speed (rpm): 6/12/30/60 (4 settings)

- Display: 3.5-inch full-color IPS screen

- Rotor Specifications: Standard: Nos. 1, 2, 3, 4; Optional: No. 0 rotor; Measurement Range: 1–100 mPa·s

- Measurement Mode: Fast

- Temperature Sensor: Temperature sensor included as standard on the PRO version

- Measurement Error: ±2% (Newtonian fluids)

- Measurement Repeatability: ±1% (Newtonian fluids)

- Display resolution: 0.01 mPa·s

- System functions: Standard measurement, unit conversion, printing (optional)

- Language: Chinese/English switching (English optional)

- Measurement logging: /

- Data interfaces: RS232, USB

- Operating environment: 0°C–40°C, 20%–80% relative humidity in a non-condensing air environment

- Power Supply: AC 100–240 V, 50/60 Hz, 2 A max, 12 V adapter

- Product Dimensions: 32 × 28 × 42 cm

- Packaged Weight: 5.2 kg

- Packaged Dimensions: 42 × 31 × 38 cm

NDJ‑5S (Color Screen Model)

- Measurement Range: 1–100,000 mPa·s

- Rotor Speed (rpm): 6/12/30/60, 4 speeds

- Display: 3.5-inch full-color IPS screen

- Rotor Specifications: Standard: Sizes 1, 2, 3, and 4; Optional: Size 0 rotor; Measurement Range: 1–100 mPa·s

- Measurement Mode: Fast

- Temperature Sensor: Temperature sensor included as standard on the PRO version

- Measurement Error: ±2% (Newtonian fluids)

- Measurement Repeatability: ±1% (Newtonian fluids)

- Display Resolution: 0.01 mPa·s

- System Functions: Standard measurement, unit conversion, printing (optional)

- Language: Chinese/English switch (English optional)

- Measurement Logging: /

- Data Interfaces: RS232, USB

- Operating Environment: 0°C–40°C, 20%–80% relative humidity in a non-condensing air environment

- Power Supply: AC 100–240 V, 50/60 Hz, 2 A max, 12 V adapter

- Product Dimensions: 32 × 28 × 42 cm

- Packaged Weight: 5.2 kg

- Packaged Dimensions: 42 × 31 × 38 cm

NDJ‑8S (Color Screen Model)

- Measurement Range: 1–2 million mPa·s

- Rotor Speed (rpm): 0.3/0.6/1.5/3/6/12/30/60 (8 settings)

- Display: 3.5-inch full-color IPS screen

- Rotor Specifications: Standard: Nos. 1, 2, 3, 4; Optional: No. 0 rotor; Measurement Range: 1–100 mPa·s

- Measurement Mode: Fast

- Temperature Sensor: Temperature sensor included as standard on the PRO version

- Measurement Error: ±2% (Newtonian fluids)

- Measurement Repeatability: ±1% (Newtonian fluids)

- Display resolution: 0.01 mPa·s

- System functions: Standard measurement, unit conversion, printing (optional)

- Language: Chinese/English switching (English optional)

- Measurement logging: /

- Data interfaces: RS232, USB

- Operating environment: 0°C–40°C, 20%–80% relative humidity in a non-condensing air environment

- Power Supply: AC 100–240 V, 50/60 Hz, 2 A max, 12 V adapter

- Product Dimensions: 32 × 28 × 42 cm

- Packaged Weight: 5.2 kg

- Packaged Dimensions: 42 × 31 × 38 cm

NDJ‑9S (Color Screen Model)

- Measurement Range: 1–6 million mPa·s

- Rotor Speed (rpm): 0.1/0.3/0.6/1.5/3/6/12/30/60 (9 settings)

- Display: 3.5-inch full-color IPS screen

- Rotor Specifications: Standard: Nos. 1, 2, 3, 4; Optional: No. 0 rotor; Measurement Range: 1–100 mPa·s

- Measurement Mode: Fast

- Temperature Sensor: Temperature sensor included as standard on the PRO version

- Measurement Error: ±2% (Newtonian fluids)

- Measurement Repeatability: ±1% (Newtonian fluids)

- Display resolution: 0.01 mPa·s

- System functions: Standard measurement, unit conversion, printing (optional)

- Language: Chinese/English switching (English optional)

- Measurement logging: /

- Data interfaces: RS232, USB

- Operating environment: 0°C–40°C, 20%–80% relative humidity in a non-condensing air environment

- Power Supply: AC 100–240 V, 50/60 Hz, 2 A max, 12 V adapter

- Product Dimensions: 32 × 28 × 42 cm

- Packaged Weight: 5.2 kg

- Packaged Dimensions: 42 × 31 × 38 cm
