Brake disc Brembo Supersport 208973712 with approval, floating front 2 pieces

  • Art. ID.: 1164163
  • Art. No.: BRE-208973712
  • Manufacturer: Brembo

General

  • Material
    Stainless steel, Aluminium
  • Placement on Vehicle
    Front
  • Included
    1x 208973712
  • Approval
    with approval
  • Type
    Brake disc
  • Features
    Floating bearing

Brakes

  • Mounting points
    6
  • Thickness (mm)
    5.5
  • Ø inner diameter (mm)
    94
  • Ø outer diameter (mm)
    320
  • Ø between holes
    6

Description

The floating-mounted Brembo 208973712 brake disc from the Xtra Supersport series was developed for sporty road motorcycles and performance-oriented riders. It combines high-quality materials with racing-proven technology and delivers outstanding braking performance during dynamic riding. The floating construction ensures optimal thermal expansion and maintains consistently high braking performance even under demanding operating conditions.

The floating mounting allows controlled movement of the stainless steel friction ring relative to the aluminium inner carrier. This reduces thermally induced stresses, improves lateral runout accuracy and ensures consistent contact between the brake pads and the brake disc. The result is a precise braking point, excellent modulation and stable braking performance at high temperatures and under heavy loads.

The friction ring, manufactured from high-quality stainless steel, features a specially developed hole pattern for effective heat dissipation, water displacement and cleaning of the friction surface. Combined with the lightweight aluminium inner carrier, unsprung mass is reduced and handling is improved. The Xtra Supersport series is based on Brembo’s many years of experience in international motorsport and offers the ideal balance of performance, durability and everyday usability.

  • Floating brake disc for sporty road motorcycles and performance-oriented riders
  • High-quality stainless steel friction ring with lightweight aluminium inner carrier
  • Reduced thermal stresses through floating mounting for high lateral runout accuracy
  • Precise braking point and excellent modulation even under high loads
  • Optimised hole pattern for improved heat dissipation, water displacement and cleaning of the friction surface
  • Reduction of unsprung mass for improved handling
  • Racing-proven Brembo technology for high performance and reliability

Technical details

  • Series: Xtra Supersport
  • Material: Stainless Steel, Aluminium
  • Storage: Floating
  • Approval: E-Approval
  • Installation position: Front

Dimensions

  • Outer diameter: 320 mm
  • Inner diameter: 94 mm
  • Brake disc thickness: 5,5 mm
  • Number of holes: 6
  • Hole diameter: 6 mm
  • Bolt circle: 110 mm

Scope of delivery

  • 1x 208973712, Brake disc Brembo Supersport 208973712 with approval, floating front 320x5,5mm 2 pieces

About the manufacturer Brembo

Brembo is recognised worldwide as a leading manufacturer of high-performance brake discs. Each disc is manufactured with the utmost precision and care to ensure optimum braking performance, even heat distribution and a long service life. Brembo brake discs deliver reliable performance in all driving conditions, from everyday use to sporty driving.

Suitable for

Brake disc Brembo Supersport 208973712 with approval, floating front 2 pieces

Honda VTR 1000 SP-1 (Bj. 2000)
Honda VTR 1000 SP-1 (Bj. 2001)
Honda VTR 1000 SP-2 (Bj. 2002)
Honda VTR 1000 SP-2 (Bj. 2003)
Honda VTR 1000 SP-2 (Bj. 2004)
Honda VTR 1000 SP-2 (Bj. 2005)
Honda VTR 1000 SP-2 (Bj. 2006)
