ZIBOO 15B PRO True RMS Digital Multimeter ,for Electrical Applications, Measures AC/DC Voltage and Current Measurements up to 1000V and 10A, Along with Resistance, Continuity, Diode, and Capacitance Capabilities



1.CAT III 600V Safety Rating: Ensuring your safety when working on electrical systems in common residential and commercial settings

2.AC/DC Voltage Measurement up to 1000V: Quickly and accurately measure both AC and DC voltage in a wide range of applications, from automotive systems to electrical panels to commercial equipment.

3.AC/DC Current Measurement up to 10A: Accurately measure AC and DC current for diagnosing electrical

Optional Current Clamp AC Current Measurement up to 600A，problems such as overloading, short circuits, and faulty wiring.

4.Voltage, Resistance （60MΩ）, Continuity, Capacitance， Diode ，Duty Cycle: Essential measurement functions for troubleshooting electrical issues in a wide range of systems, allowing you to quickly diagnose and repair problems.

5.6000 Counts True RMS，VFD AC 600V（Variable Frequency） ，NCV/LIVE , Red LED Flash ，Continuity Buzzer Green LED Flash





SPECIFICATIONS



ZIBOO 15B PRO True RMS Digital Multimeter

Compact, reliable digital multimeter for basic electrical testing.



The ZIBOO 15B PRO True RMS Digital Multimeter measures AC/DC voltage up to 1000V and AC/DC current up to 10A.Optional Current Clamp AC Current Measurement up to 600A, It features resistance, continuity, diode, and capacitance testing capabilities, ensuring accurate readings for a wide range of electrical applications. With a CAT III 600V and CAT II 1000V rating, it helps keep you safe when working on electrical systems. Whether you're a DIY enthusiast or a professional electrician, this reliable and versatile tool is an essential addition to your toolkit.



CAT III 600V Safety Rating: Ensuring your safety when working on electrical systems in common residential and commercial settings

AC/DC Voltage Measurement up to 1000V: Quickly and accurately measure both AC and DC voltage in a wide range of applications, from automotive systems to electrical panels to commercial equipment.

AC/DC Current Measurement up to 10A: Accurately measure AC and DC current for diagnosing electrical problems such as overloading, short circuits, and faulty wiring.

Voltage, Resistance, Continuity, Capacitance: Essential measurement functions for troubleshooting electrical issues in a wide range of systems, allowing you to quickly diagnose and repair problems.

Input Terminal for AC/DC Current Measurements to 10A: Allowing you to get accurate readings for a variety of electrical applications.

Diode Test: Allows you to quickly and accurately identify faulty diodes, saving you time and money on repairs.

Data Hold: Freezes the multimeter's reading, allowing for easier analysis and recording of measurements.

Large Easy-to-Read Display with Bright White Backlight: Making it easy to read measurements in any lighting condition, even in dimly lit areas.

6000 Counts True RMS，VFD AC 600V（Variable Frequency） ，NCV/LIVE , Red LED Flash ，Continuity Buzzer Green LED Flash



======================



ZIBOO 17B PRO True RMS Digital Multimeter ,for Electrical Applications, Measures AC/DC Voltage and Current Measurements up to 1000V and 10A, Along with Resistance, Continuity, Diode, and Capacitance Capabilities



1.CAT III 600V Safety Rating: Ensuring your safety when working on electrical systems in common residential and commercial settings

2.AC/DC Voltage Measurement up to 1000V: Quickly and accurately measure both AC and DC voltage in a wide range of applications, from automotive systems to electrical panels to commercial equipment.

3.AC/DC Current Measurement up to 10A: Accurately measure AC and DC current for diagnosing electrical

Optional Current Clamp AC Current Measurement up to 600A，problems such as overloading, short circuits, and faulty wiring.

4.Voltage, Resistance （60MΩ）, Continuity, Capacitance， Diode ，Duty Cycle: Essential measurement functions for troubleshooting electrical issues in a wide range of systems, allowing you to quickly diagnose and repair problems.

5.6000 Counts True RMS，VFD AC 600V（Variable Frequency） ，NCV/LIVE , Red LED Flash ，Continuity Buzzer Green LED Flash







SPECIFICATIONS



ZIBOO 17B PRO True RMS Digital Multimeter

Versatile digital multimeter for a wide range of electrical testing applications.

The ZIBOO 17B+ Digital Multimeter is a great tool for electricians and DIY enthusiasts who want quality, accuracy, and safety. It features AC/DC voltage and current measurements up to 1000V and 10A, along with resistance, continuity, diode, capacitance, frequency, and temperature testing capabilities. Its CAT III 600V rating and overload protection give you confidence in your safety, and its large backlit display, small size, and ruggedness make it ideal for on-the-go electrical system testing.

CAT III 600V Safety Rating: Ensuring your safety when working on electrical systems in common residential, commercial, and industrial settings.

AC/DC Voltage and Current Measurements up to 1000V and 10A: Allowing you to get accurate readings for a variety of electrical applications.

Resistance, Continuity, Capacitance: Essential measurement functions for troubleshooting electrical issues in a wide range of systems, allowing you to quickly diagnose and repair problems.

Diode Test: Allows you to quickly and accurately identify faulty diodes, saving you time and money on repairs.

Temperature measurement: Provides easy monitoring of heating and cooling systems up to 1000°C with included type K thermocouple.

Frequency measurement range up to 400kHz: Providing accurate readings for a variety of electrical applications.

Data Hold: Freezes the multimeter's reading, allowing for easier analysis and recording of measurements.

Large Easy-to-Read Display with Bright White Backlight: Making it easy to read measurements in any lighting condition, even in dimly lit areas.

6000 Counts True RMS，VFD AC 600V（Variable Frequency） ，NCV/LIVE , Red LED Flash ，Continuity Buzzer Green LED Flash





SPECIFICATIONS 　 　 　
Function/Model ZIBOO 15B PRO ZIBOO 17B PRO Accuracy
DC mV 60.00mV/600mV 60.00mV/600mV ±(0.5%+3）
DCV 6V/60V/600V/1000V 6V/60V/600V/1500V ±(0.5%+3）
AC mV 60.00mV/600.0mV 60.00mV/600.0mV ±(0.8%+5）
ACV
/Bandwidth (Hz)		 6V/60V/600V/1000V
1kHz		 6V/60V/600V/1000V
1kHz		 ±(0.8%+5）
VFD(AC Voltage）
Variable Frequency		 100~600V/400Hz 100~600V/400Hz ±(4%+5）
DC Current (A) 600.0uA
6mA/60mA/600mA
6.000A/10A		 600.0uA
6mA/60mA/600mA
6.000A/10A		 ±(0.8%+5）
±(0.8%+5）
±(1.5%+5）
AC/DC600A
( Current Clamp)		 0.1A~600.0A
 (Input 1A=1mV)		 0.1A~600.0A
 (Input 1A=1mV)		 ±(3%+5）
Frequency ( Hz)
Duty%		 10Hz~20MHz
10%~90%		 10Hz~20MHz               10%~90% ±(0.5%+5）
±(2%+5）
Resistance (Ω) 600Ω/6KΩ/60KΩ/600KΩ
6MΩ/60MΩ		 600Ω/6KΩ/60KΩ/600KΩ
6MΩ/60MΩ		 ±(0.8%+5）
±(2.5%+5）
Capacitance(F) 60nF~600nF~600uF
6000uF~60000uF		 60nF~600nF~600uF
6000uF~60000uF		 ±(4%+5）
±(8%+5）
Temperature(°C ) 　 (-50°C~1000°C) ±(1..5%+4）
Temperature( °F) 　 (-58°C~1832°F) ±(2%+4）
Display Counts 6000 6000 　
Auto Range Auto Auto
Auto power off ✓  ✓  　
True RMS ✓  ✓
Connuity/Diode ✓  ✓  　
VFD(Variable Frequency ✓  ✓
NCV (Red LED  ✓  ✓  　
AC Live ✓  ✓
Auto power off ✓  ✓  　
PACKAGING INFORMATION 　 　
Battery AA1.5Vx3 not include AA1.5Vx3not include 　
Product Weight 402g 402g 　
Standard Accessories Test Lead, Thermocouple (only 17B PRO) ,  Optional ZIBOO i600e Current Clamp (not include )
