Description

This mechanism creates a in state when the trip point is reached.In snap action contacts, the movement of the actuator applies force to an overcenter mechanism. Widely used in electronic equipments, Microwave Micro Door/Oven/Refrigerator Interlock N/O / etc.These Micro features Single Pole Double Throw (SPDT) Type, 1NO + 1NC Contact, Momentary Action, Hinge Roller Lever Actuator.Easy installation and long using life. Reversing the motion of the actuator to a given reset point causes the contacts to snap back to their original position

Features

- Snap action contacts have different trip and reset points. The distance between the trip and reset point is called the travel to reset, , or differential. Finite travel to reset helps to avoid multiple changes of state if the object actuating the is subject to vibration.
- Roller Diameter : 4.5mm/0.2"Mounting Hole Dia. : 2mm / 0.08".
- Voltage: 125-250V.
- Overall Size(Pole not included) : 20 x 6 x 10mm / 0.8" x 0.2" x 0.4" (L*W*H).
- Mounting Hole Spacing : 9mm/ 0.35";Material : Plastic, Metal
- Hinge Roller Lever Length : 18mm/0.7".
- Snap action contacts ensure repeatable performance in applications that involve low actuators. The amount of travel of the contacts is also not dependent on the amount of travel by the actuator.
Weight : 22g.
- ColorBlack

1 * 10 Pcs Roller Lever Arm SPDT Snap Action LOT
