AD-LINNK PCIe X8 to X8 Adapter for Graphics Video Card PCI Express Extender PCIe X8 to PCIe X8 slot Extension Cable For 1U 2U server

ADT-Link PCI express 3.0 x16 to x8 Extension Cable

Note:Due to production batch issues, the appearance may change somewhat, but does not affect its usage.

Brand name: ADT-LINK

Product name: PCIe x8 to x8 extension cable

Product model: R88SF

Transfer speed: PCIe3.0 x8 to x8, 64G/bps (Max.)

Wire length: 5 ~ 100 cm, the length can be customized,

Application: PCIe x8 to PCIe x8 slot extension cable

Cable length Description:

The length of the wire refers to the part of the visible wire. It does not include the PCB and the connector. For the wire length, please refer to the 20cm blue arrow in the figure below.
