Compatible with Bombardier Outlander. Compatible with Can-Am Commander, Defender, Maverick (Non X3), Outlander, Renegade. To prevent fitment problems, please check the year and model in the description. May fit others, verify using the listed specifications. RockTrix Wheel Offroad Beadlock ATV Rim - Fits machines with 4/137 Bolt Pattern and a hub bore no larger than 110mm. Works with various ATV, UTV, Side by Side, Quads. Verify fitment by checking that your machine's bolt pattern, center hole, and offset match that of our ATV wheels before making your purchase. [Features] Precise, CNC Machined, solid cast, lightweight aluminum wheel with a matte black finish and polished beadlock ring. Topped with a high quality clear coat that is scratch, rust, and corrosion resistant to ensure your wheels never look cheap. This 14in tire rim is perfect for motorsports, offroad, or daily travel. Designed for both on-road and off-road use. For daily street driving, mount tires onto the traditional bead seats. For off-road, secure tires using the beadlock rings. [Important] We recommend professional installation as instructions are not provided. For your safety, retorque all nut hardware after 25-50 miles. We recommend removing center caps before entering trails with deep mud or thick bush. Tires secured using beadlock rings are for off-road use only. Beadlock ring spacers may be needed for proper installation if your tire bead thickess is more than 8mm (5/16"). Failure to verify this may damage the beadlock ring/hardware or cause an air leak.




ROCKTRIX RT104BL WHEEL FEATURES

RockTrix Wheel Offroad Beadlock ATV Rim - Fits machines with 4/137 Bolt Pattern and a hub bore no larger than 110mm. Works with various ATV, UTV, Side by Side, Quads. Verify fitment by checking that your machine's bolt pattern, center hole, and offset match that of our ATV wheels before making your purchase.

Compatible with Bombardier Outlander. Compatible with Can-Am Commander, Defender, Maverick (Non X3), Outlander, Renegade. To prevent fitment problems, please check the year and model in the description. May fit others, verify using the listed specifications.

This listing is for one single (1) ATV UTV Beadlock Wheel RockTrix Rim - 14" Diameter, 4+3 (ET10) Offset, 14x7 Size, 4x137 Bolt Pattern, 110m Bore, 1100lb Load Rating per wheel. Beadlock Ring & Beadlock Bolts Included. One (1) RockTrix Center Cap included. Valve Stems Not Included. Lug Nuts Not Included. See Description for More Details.

[Features] Precise, CNC Machined, solid cast, lightweight aluminum wheel with a matte black finish and polished beadlock ring. Topped with a high quality clear coat that is scratch, rust, and corrosion resistant to ensure your wheels never look cheap. This 14in tire rim is perfect for motorsports, offroad, or daily travel. Designed for both on-road and off-road use. For daily street driving, mount tires onto the traditional bead seats. For off-road, secure tires using the beadlock rings.

[Important] We recommend professional installation as instructions are not provided. For your safety, retorque all nut hardware after 25-50 miles. We recommend removing center caps before entering trails with deep mud or thick bush. Tires secured using beadlock rings are for off-road use only. Beadlock ring spacers may be needed for proper installation if your tire bead thickess is more than 8mm (5/16"). Failure to verify this may damage the beadlock ring/hardware or cause an air leak.






























Item Condition Information
Wheel is in perfect working condition. The wheel has minor cosmetic blemishes (scuffs / scratches / nicks). Note that the wheel may have had a tire mounted on it and may show signs of minor use. The wheel has been though balance, run-out, and road force testing to ensure there are no bends or structural issues. Original protective wrapping is intact, but may not come with the original box. Includes a centercap.

Important Note About Pictures
Please note that the pictures depicts a "new" product and will not be the actual item you will receive.  If you have any questions or concerns, please message us.

WHEEL SPECIFICATIONS

Quantity One (1) Wheel
Model RT104BL
Size 14x7
Bolt Pattern 4x137
Offset 4+3 (ET10)
Centerbore 110mm
Construction 1-Piece Cast Aluminum
Load Rating 1100 lbs (per wheel)
Color Matte Black

ATV FITMENT LIST

IMPORTANT 1: Tires secured using beadlock rings are for off-road use only may not be legal for highway use.
IMPORTANT 2: Designed for both on-road and off-road driving. For daily street driving, mount tires onto the traditional bead seats. For off-road driving, secure tires using the beadlock rings.
IMPORTANT 3: Beadlock ring spacers may be needed for proper installation. Some tires feature thicker beads, which prevents the beadlock ring from properly clamping the tire to the wheel. This may damage the beadlock ring/hardware and/or cause an air leak. From our experience, if your tire bead thickness is more than 8mm (5/16"), you may need beadlock ring spacers.

Bombardier
2003-2005 Outlander 330
2003-2006 Outlander 400
2004-2006 Outlander Max 400

Can-Am
2022-2023 Commander 700
2011-2015 Commander 800
2011-2020 Commander 800R
2011-2020 Commander 1000
2018-2023 Commander 1000R
2014-2016 Commander Max 1000
2013-2015 Commander Electric
2014-2017 Commander Max 1000
2018-2023 Commander Max 1000R
2016-2023 Defender HD10
2017-2021 Defender HD5
2022-2023 Defender HD7
2016-2021 Defender HD8
2022-2023 Defender HD9
2017-2023 Defender Max HD10
2022-2023 Defender Max HD7
2017-2021 Defender Max HD8
2022-2023 Defender Max HD9
2020-2023 Defender Pro HD10
2013-2018 Maverick 1000R
2013-2018 Maverick Max 1000R
2019-2022 Maverick Sport 1000
2019-2023 Maverick Sport 1000R
2019-2023 Maverick Sport Max 1000R
2019-2023 Maverick Trail 1000
2022-2023 Maverick Trail 700
2019-2021 Maverick Trail 800
2012-2018 Outlander 1000
2016-2023 Outlander 1000R
2007-2014 Outlander 400
2017-2023 Outlander 450
2007-2023 Outlander 500
2016-2023 Outlander 570
2007-2022 Outlander 650
2007-2008 Outlander 800
2009-2015 Outlander 800R
2016-2023 Outlander 850
2015-2016 Outlander L 450
2015-2017 Outlander L MAX 450
2013-2023 Outlander Max 1000
2018-2023 Outlander Max 1000R
2008-2015 Renegade 500
2016-2022 Renegade 570
2007-2008 Renegade 800
2009-2015 Renegade 800R
2016-2022 Renegade 850
2012-2015 Renegade 1000
2016-2023 Renegade 1000R

Important Notes




	 FINAL SALE ITEM - Cannot be returned/exchanged. It is extremely important for you to double check fitment and the notes below before purchasing.



	 Before purchasing, double check your ATV's bolt pattern, centerbore, and offset to ensure 100% compatibility.

	 Your vehicle's wheel studs must be at least 21mm (13/16") in length to safely install these wheels.

	 Wheels requires Acorn / Conical / Cone Seat lug nuts (Lug Nut Diameter must be less than 22mm).



	 Wheel includes 1 centercap as seen in the pictures.

	 Valve Stems are not included.

	 Lug Nuts are not included.



	 We recommend removing the center cap before entering deep mud or thick brush.

	 Professional installation is recommended as instructions are not provided.

Legal Information



NOTE: This is an aftermarket component. The vehicle makes/models used in this listing are registered trademarks of their respective owners, and are used in this listing to identify compatibility.
