TDRFORCE Pressure Booster Pump
Designed and intended to boost home water pressure or as a shallow well jet pump with an electronic control. Whether you're in the shower or using the faucet, this powerful pressure booster will keep your water pressure going strong. Besides, it is also applied in irrigation for farmlands and garden, domestic well and water tower, as well as providing water for solar at high floors. Easy to carry with a handle; easy to install and use.The integrated electronic control which maintains pressure and flow can protect the pump from running dry.
Recommended for household water supply, water supply system, cooling system and boost system.
Features:
- Powerful pressure booster pump delivering full flow and pressure, easy to prime
- Auto-activation when water runs, great for continuous duty
- Tighten the water inlet and outlet during use, otherwise the O-ring will run out and cause water leakage.
- Since the controller is used to control the water flow, it cannot be forced to shut down automatically. If you want to turn off the water pump, you must manually unplug the power supply.
- Ideal as a pressure booster or a conventional shallow well jet pump with an electronic control, recommended for residential use in homes, cottages, farms, gardens and solar
JETS-60
- Power: 370W(1/2Hp)
- Max Pressure: 44PSI
- Body Materials: Stainless steel, PPO
- Voltage: 115V Current: 5.4A
- Frequency: 60Hz Speed: 2850rpm
- Capacitor: 20UF
- Pipe Size: 1”×1”
- Max.Head: 32m(104ft)
- Product Weight: 9.1kg/20lb
- Max Flow(Liters/Min): 55L/Min(14.5GPM)
- CE, IP45 Protection, Insulation Class B
JETS-80
- Power: 550W(3/4Hp)
- Max Pressure: 52PSI
- Body Materials: Stainless steel, PPO
- Voltage: 115V Current: 6.8A
- Frequency: 60Hz Speed: 2850rpm
- Capacitor: 30UF
- Pipe Size: 1”×1”
- Max.Head: 34m(111ft)
- Product Weight: 12.05kg/26.56lb
- Max Flow(Liters/Min): 65L/Min(17GPM)
- CE, IP45 Protection, Insulation Class B
Shipping:
- Fedex or UPS Ground, usually takes 3-5 business days to destinations. Shipping from Los Angeles, CA.
Attention:
- Liquid Requirements: Clean liquids without suspended solids, non-aggressive (Liquid temperature: -20℃~+40℃). Not recommended for sand point applications and please avoid sand pumped into pump body.
- If the pump remain unused for a long period of time, please empty it to prevent formation of deposits or increase of water volume due to frozen water, which could tear the fixing bolts or cracking the pump body.
- When starting the pump again, refill it and check that the shaft runs free by introducing a screw-driver into the slot on the shaft, on the fan side.
- Please carefully read over the operation manual before use for the sake of its proper application and optimum efficiency.
