●The price displayed on the product includes VAT, not the final price.
Ship from China, you don’t need to pay any taxes (value-added tax, customs duties, agency fees, etc.) when you place an order
●Shipping from Spain is subject to tax.
Please rest assured to buy! ! !
【Note】
■1.28/29inch700C are the same size. The 28inch label on our wheels and 29inch700C can be used. Please rest assured.
■2.The default motor of the kit is the above motor, not the carton motor. If you need a cassette motor, you need to contact us and pay an additional fee of $10.
■3.The cassette tape drive may only be delivered from China. There are no cassette motors in stock in the Polish/Spain warehouse. The kit includes a flywheel. Excluding disc brake disc and tirque arm
■4.Packing List: Please see the SKU images, the product details are subject to the picture.
Packing List :
Noted:Conversion Kit not include Battery, tire, tirque arm,disc brake.( If you need a Battery, tire, tirque arm, disc brake, Please contact us for an additional fee )
●1 * Motor wheel(Front or Rear)
●1 * Controller
●1 * Controller Bag/box
●1 pair * Power cut-off Brake lever
●1 pair * Brake sensor
●1 * Display LCD3 or LCD4
●1 * 8 Magnet Pedal Assistant Sensor
●1 * Throttle
Our service:
●Battery warranty:one year
●Motor warranty:one year
●Accessories warranty:three months
●Message response time:We will reply to each customer's message as soon as possible, and we will not let you wait too long.
Motor characteristics:
●[Easy installation]Easy to modify, DIY electric bicycle modification kit, suitable for front wheel or rear wheel, bicycle with front wheel size "100mm" and bicycle with rear wheel size "135-142mm" can easily take you within 1 hour Converted bicycles to electric bicycles;
●[Popularity]Stable drive system. This mountain bike motor is compatible with disc brakes and V brakes, and is powerful and efficient. This motor greatly improves riding comfort;
●[Powerful]Super cost-effective, efficiency ≥80%; the brake lever safely cuts off the power of the motor;
●[Complete Accessories]is equipped with all necessary accessories. Front wheel/rear wheel and motor, controller, display (optional), brake lever, thumb throttle, PAS, extension cable, controller package;
●[Four riding modes]Pure electric mode & human body riding mode & assist & push mode. 4 working modes can be switched at will;
●[Installation Manual]Before installing the motor, please connect the motor according to the steps in the manual to see if the motor can work normally. If you have any questions, please contact us first, we will provide technical support, please don’t worry;
●[Applicable]Our motors are suitable for disc brakes and V brakes;
●[Not recommended]We do not recommend that you install a motor kit on a carbon fiber bike
●[DDP Service]The following countries include DDP service. Taxes and fees are paid by us. (Russian Federation, United States, Canada, Ukraine, South Korea, Germany, France, Spain, Netherlands, Italy, Bulgaria, Belgium, Latvia, Poland, Denmark, Finland, Portugal, Sweden, Slovakia, Slovenia, Greece, Hungary, Czech Republic, Lithuania , Luxembourg, Romania, Ireland, Estonia, Austria, Croatia, Australia)
●[Delivery]Fast delivery speed, delivery within 48 hours after placing the order.
Gifts: 1 * Controller Bag( not battery) +1 * Flywheel（Only in the Rear）+1*Install cable ties and stretch film+1*Installation Manual
Motor Wheel Detail:
●250W【Gear】about 25-28km/h 207-270 RPM 29-31.2NM
●350W【Gear】about 25-28km/h 231-270 RPM 31.8-33NM
●500W【Gear】about 30-32km/h 265-325 RPM 60-63NM
●1000W 【Gearless】about 35-40km/h 325-331RPM 57.5-59NM
●1500W 【Gearless】about 45-50km/h 414-487 RPM 71-74.6NM
(different wheel size, road&weather condition and rider's weight will have different speed)
●Rim:Double-wall Aluminium Alloy Rim
●Dropout:
●Front wheel 100mm,
●Rear wheel 135mm.
●Motor Brake Type:V/Disc Brake.
About Controller:
Controller Type: Brushless Motor Controller
●250W use KT 15A controller
●350W use KT 15/17A controller
●500W use KT 22A controller
●48V 1000W/1500W use KT 30A/35A controller.
About Rim size:
●250W motor default P19D Rim ( Fit 1.5-1.95 Bike Tire)
●350W motor default P19D Rim ( Fit 1.5-1.95 Bike Tire)
●500W motor default P19D Rim ( Fit 1.5-1.95 Bike Tire)
●1000W/1500W motor default P25 rim ( Fit 1.75-2.125 Bike Tire)
●If you have special requirements, please contact us.
Ship from China
[Please notice the ATTENTION information below]
We have the following options:
●wheel:Front wheel or Rear (Cassette need pay extra 10 dollars)
●wheel size :16inch,20inch,24inch,26inch ,27.5inch ,28inch,29inch,700C (leave message when you order)
●Throttle:Half Twist Throttle , Thumb Throttle , Twist Throttle （Depend the type you choose）
Ship from Russian Federation
[Its not optional and can't change parts,Please leavea message to confirm the wheel size agianafter you place an order]
We have the following Option:
●48V 1500W，26inch，Front wheel
Ship from Spain
[Its not optional and can't change parts,Please leavea message to confirm the wheel size agianafter you place an order]
We have the following Option:
●36V 350W，26inch，Rear wheel
●36V 500W，26inch，Rear wheel
●48V 1000W，26/27.5/28inch，Rear wheel
●48V 1500W，26/27.5/28inch，Rear wheel
