P2015 Manifold Intake Repair Bracket for VW Audi Skoda Seat 2.0TDI CR 03L129711E
Feature
【Product Name】Volkswagen rearview mirror repair kit
【Color】Silver
【Type】 Repair Bracket
【Material】Aluminum
【Quantity】1Set (as shown）
【Product Name】Volkswagen rearview mirror repair kit
【Color】Silver
【Type】 Repair Bracket
【Material】Aluminum
【Quantity】1Set (as shown）
Specification
1. Triggered P2015, P2002, P2009, P2017 TDI codes, engine management light, intake manifold flap position sensor fault.
2. Excessive movement of the V157 intake flap motor which can open or close too far due to wear and tear causing the P2015 fault
3. Fitting our specially designed bracket limits the range of movement of the flap, thus preventing the fault trigger.
4. This part is easy to fit and does not require any computer programming or alterations, but mounts directly to an existing screw hole, curing this fault for the life of the vehicle.
1. Triggered P2015, P2002, P2009, P2017 TDI codes, engine management light, intake manifold flap position sensor fault.
2. Excessive movement of the V157 intake flap motor which can open or close too far due to wear and tear causing the P2015 fault
3. Fitting our specially designed bracket limits the range of movement of the flap, thus preventing the fault trigger.
4. This part is easy to fit and does not require any computer programming or alterations, but mounts directly to an existing screw hole, curing this fault for the life of the vehicle.
Fitment：
All VAG 2.0TDI common rail engines 2008 - 2014 with aluminium manifold
Actuator motor No. 03L129086 & 03L129711E
CAAB 2.0 102 HP
CAGA 2.0 143 HP
CAGB 2.0 136 HP
CAGC 2.0 120 HP
CAHA 2.0 170 HP
CAHB 2.0 163 HP
CBAA 2.0 136 HP
CBAB 2.0 140 HP
CBAC 2.0 143 HP
CBBB 2.0 170 HP
CBDA 2.0 136 HP
CBDB 2.0 140 HP
CBDC 2.0 110 HP
CEGA 2.0 170 HP
CJAA 2.0 140 HP
CMEA 2.0 143 HP
All VAG 2.0TDI common rail engines 2008 - 2014 with aluminium manifold
Actuator motor No. 03L129086 & 03L129711E
CAAB 2.0 102 HP
CAGA 2.0 143 HP
CAGB 2.0 136 HP
CAGC 2.0 120 HP
CAHA 2.0 170 HP
CAHB 2.0 163 HP
CBAA 2.0 136 HP
CBAB 2.0 140 HP
CBAC 2.0 143 HP
CBBB 2.0 170 HP
CBDA 2.0 136 HP
CBDB 2.0 140 HP
CBDC 2.0 110 HP
CEGA 2.0 170 HP
CJAA 2.0 140 HP
CMEA 2.0 143 HP
Package included：
1x Repair bracket kit (bracket, top clamp, cap screw)
1x Repair bracket kit (bracket, top clamp, cap screw)
