Set of 4, 5 or 6 CBN sharpening stones, metal and combined(metal-resin) bonds, for curved blades,
Poltava plant of diamond tools,
150 х 12 х 7 x 3
Length: 150 mm = 6 inch
Width: 12 mm = 0,5 inch
CBN thickness: 3 mm = 0.12 inch
Blank thickness: 4 mm = = 0.16 inch
Total thickness: 7 mm = 0.28 inch
Trademark: Aldim. These next generation stones were developed on the basis of our experience in sharpening business:
- solid support plate (thicker aluminum blank: 4 mm vs competitors' 3 mm);
- appropriate bonds (selected, depending on grain size)
- combination of long life, delicate sharpening, and excellent performance of combined (metal-resin) bond.
Appication: metal and combined (metal-resin) bond CBN sharpening stones for sharpening of curved (s-shaped) blades
Concentration 100%.
Flat solid block on aluminum blank, grains are distributed evenly across the stone.
Material: CBN - cubic boron nitride. It has the best cost/productivity ratio for processing of steels, comparing to diamond and cheaper stones, they are similar in qualities to Japanese wet stones, but have ten times longer working life. CBN is a generic name, there are also other names of this material, depending on manufacturer: borazon, elbor.
Sharpening stones in sets (grain size format: Micron(UA) = ANSI(US) = FEPA(EU)
Set of 4 stones:
1. 100/80μ = 140/170 = D107, metal bond M2-01 - rough sharpening
2. 50/40μ = 270/325 = D54, combined (metal-resin) bond BP50 - fine sharpening
3. 20/14μ = 1100 = M20, combined (metal-resin) bond BP50 - polishing
4. 7/5μ = 3000 = M6.3, combined (metal-resin) bond BP50 - polishing
Set of 5 stones:
1. 100/80μ = 140/170 = D107, metal bond M2-01 - rough sharpening
2. 50/40μ = 270/325 = D54, metal bond - sharpening
3. 28/20μ = 650 = M25, combined (metal-resin) bond BP50 - polishing
4. 14/10μ = 1500 = M16, combined (metal-resin) bond BP50 - polishing
5. 7/5μ = 3000 = M6.3, combined (metal-resin) bond BP50 - polishing
Set of 6 stones:
1. 160/125μ = 100/120 = D151, metal bond M2-01 - rough sharpening
2. 80/63μ = 170/200 = D91, metal bond - sharpening
3. 40/28μ = 550 = M40, combined (metal-resin) bond BP50 - polishing
4. 20/14μ = 1100 = M20, combined (metal-resin) bond BP50 - polishing
5. 10/7μ = 1700 = M10, combined (metal-resin) bond BP50 - polishing
6. 5/3μ = 4000 = M4, combined (metal-resin) bond BP50 - polishing
Preparation
Stones in these sets do not require preparation and are ready to use out of the box, information below is just for consideration.
Stones with grits finer 3 microns either may require preparation (polishing) with SiC powders, or they will be self-polished after sharpening of 30-50 knives. Then they will be of gold color and work well. The image below shows surface of 0.5/0 stone under microscope, before and after polishing with SiC powders.
Use and cleaning
Use any comfortable oil (baby, olive..) to prevent glazing. If glazed - clean with alcohol and toothbrush.
Maintenance is only needed every year or two.
In 1-2 years you may need to flatten stone:
In 1-2 years you may need to flatten stone:
-Metal bond stone: polish it with SiC powders (grain size selection list below), or use Ferric chloride (FeCl, video below):
- 10 mins setting in 25% mixture (25 gr FeCl per 75 gr of water),
- 10 mins polish movements (carefully draw "8") on glass plate.
-Combined and resin bond stones: polish them with SiC powders.
Selection of SiC powders for dressing of sharpening stones
| Stone | Starting grit | Finishing grit |
| 500/400 μ = 35/40= D501 | F16 (1230 μ) | F24 (745 μ) |
| 400/315 μ = 40/45= D426 | F16 (1230 μ) | F46 (370 μ) |
| 315/250 μ = 50/60= D301 | F24 (745 μ) | F46 (370 μ) |
| 250/200 μ = 60/70= D251 | F24 (745 μ) | F60 (260 μ) |
| 200/160 μ = 70/80= D213 | F36 (525 μ) | F60 (260 μ) |
| 160/125 μ = 100/120= D151 | F46 (370 μ) | F80 (180 μ) |
| 125/100 μ = 120/140= D126 | F60 (260 μ) | F100 (129 μ) |
| 100/80 μ = 140/170= D107 | F60 (260 μ) | F120 (109 μ) |
| 80/63 μ = 170/200= D91 | F80 (180 μ) | F150 (82 μ) |
| 63/50 μ = 230/270= D64 | F100 (129 μ) | F180 (69 μ) |
| 50/40 μ = 270/325= D54 | F120 (109 μ) | F220 (58 μ) |
| 40/28 μ = 550= M40 | F150 (82 μ) | F240 (46 μ) |
| 28/20 μ = 650= M25 | F180 (69 μ) | F320 (30 μ) |
| 20/14 μ = 1100= M20 | F240 (46 μ) | F400 (18 μ) |
| 14/10 μ = 1500= M16 | F320 (30 μ) | F400 (18 μ) |
| 10/7 μ = 1700= M10 | F400 (18 μ) | F600 (10 μ) |
| 7/5 μ = 3000= M6.3 | F600 (10 μ) | F800 (6,7 μ) |
| 5/3 μ = 4000= M4 | F600 (10 μ) | F800 (6,7 μ) |
| 3/2 μ = 6000= M1.5 | F800 (6,7 μ) | F1200 (3 μ) |
| 2/1 μ = 10000 | F800 (6,7 μ) | F1200 (3 μ) |
| 1/0 μ | F800 (6,7 μ) | F1200 (3 μ) |
| 0.5/0 μ | F800 (6,7 μ) | F1200 (3 μ) |
Please review stone flattening/revitalization video with FeCl below.
CBN metal bond stones flattening and revitalization
Video will open in a new window
Using the eBay App? Paste link into a browser window:
Grain size/operation reference chart
30000 grit = 0.5/0 μ - fine polishing
15000 grit = 1/0 μ - fine polishing
10000 grit = 2/1 μ - fine polishing
5000 grit = 3/2 μ - fine polishing
4000 grit = 5/3 μ - polishing
3000 grit = 7/5 μ - polishing
1700 grit = 10/7 μ - polishing
1500 grit = 14/10 μ - polishing
1100 grit = 20/14 μ - polishing
650 grit = 28/20 μ - polishing
550 grit = 40/28 μ - fine grinding
325 grit = 50/40 μ - fine grinding
285 grit = 63/50 μ - fine grinding
240 grit = 80/63 μ - fine grinding
225 grit = 100/80 μ - fine grinding
160 grit = 125/100 μ - grinding
100 grit = 160/125 μ - grinding
80 grit = 200/165 μ - sharpening / rough grinding
My listings of Poltava sharpening/honing stones (Length x Width x Abrasive Thickness, mm):
Diamond sharpening stones: not recommended for steels with high carbon content, but perform well with hard steels, like CPM S90V.
CBN sharpening stones: standard for steels.
Combined bond: next generation bond, combines delicacy of resin bond on fine grains, and wear resistance of metal bonds on coarse grain sizes.
Sets: preselected stones to make your choice easier: metal and combined bond sharpening stones on blanks.
Pro 200% - professional stones with concentration 200% (standard stones are 100% concentration), which means higher productivity and longer tool's life.
Economy: cost saving solution for most sharpening applications.
"Pro" and "Economy" are the only nicknames I use for stones and I suppose it's clear why. No pathetic nicknames and brands. Just product as it should be, from trusted Poltava seller.
"Pro" and "Economy" are the only nicknames I use for stones and I suppose it's clear why. No pathetic nicknames and brands. Just product as it should be, from trusted Poltava seller.
Made in Ukraine
