Molecular Devices Axon GenePix 4000B Microarray Scanner
- SKU: ST0038057
- Brand: Molecular Devices/Axon Instruments
- Condition: Used
- Notes: Clean, in good condition. No power supply
- Inspected By: 2
- Item ID: 38057
- Model: GenePix 4000B
- Electrical Req: 120/240V | 50/60Hz
Clean and in good cosmetic condition. Removed from a high profile state lab during an upgrade but we were unable to locate the power supply.
Tech notes from the laboratory showed that the unit was functional at the time of the upgrade, however we are unable to independantly test onsite without the propietary PSU.
Comes as shown.
Manufacturer Description
The GenePix® 4000B Microarray Scanner from Molecular Devices is a benchmark for quality, reliability and ease-of-use in microarray scanning technology. Coupled with GenePix® Pro Microarray Image Analysis Software and Acuity® microarray informatics software, the GenePix System sets the highest standards in the acquisition and analysis of data from all types of arrays, including nucleic acids, proteins, tissues, and cells.
Features & Benefits
- Hands-free SmartCapture Technology™
- No camera or focus adjustment required
- Application flexibility
- Multiple excitation sources for nucleotide and protein stains
- Absorbance for Ponceau-stained membranes or petri dishes
- Publication-quality images
- 4,096 grayscales with 5 million pixels for excellent resolution
- Universal TIFF and JPEG file formats
- Small footprint, large format
- Compact footprint fits right on your bench top
- Accommodates large format protein and nucleotide gels (i.e. PROTEAN II, Subcell 96)
| Performance Specification | ||
| Sample type | Standard microscope slide (1″ x 3″, 25 x 75 mm or 26 x 76 mm) | |
| Scan area | Adjustable, 22 x 71.5 mm max | |
| Excitation | 532 nm and 635 nm lasers | |
| Laser power settings | User-selectable 100%, 33% or 10% laser power | |
| Emission filters | Two, optimized for Cy3 and Cy5 or spectrally similar dyes | |
| Detection | Dual photomultipliers (PMTs), automatic and manual gain adjustment | |
| Focus offset | Adjustable between -50 and +200 μm (5 μm increments | |
| Optics | Non-confoca | |
| Focus offset | Adjustable between -50 and +200 μm (5 μm increments | |
| Scanning method | Simultaneous, 2-channel | |
| Scan time | 6.5 minutes for both channels, 10 μm resolution, full scan area | |
| Pixel resolution | Adjustable from 5–100 μm | |
| Digital resolution | 16-bit | |
| Dynamic range | Four orders of magnitude at SNR > 3 | |
| Image type | Single- or multi-image TIFF | |
| Barcode reading | Image-based software barcode reader | |
| Dimensions (in.) | 13.5 (W) x 8.0 (H) x 17.5 (D) | |
| Dimensions (cm) | 34 (W) x 20 (H) x 44 (D) | |
| Weight | 45 lbs. (20 kg) | |
