It has the advantages of bi-directional tension and compression, compact structure, high comprehensive precision, good long-term stability and nickel plating on the surface of high-quality alloy steel
Automobile press ptting, automatic assembly, 3C product testing, new energy product assembly, medical testing, robotics, mold assembly and other industrial testing, automation equipment and testing pelds
Specification:
Capacity: 0-2T
Rated Output: 1.0-2.0±0.05mV/V
Zero Balance: ±1%F.S.
Non-Linearity: 0.5%F.S.
Hysteresis: 0.3%F.S.
Repeatability: 0.3%F.S.
Creep (30min): 0.1%F.S.
Temp Effect on Output: 0.1%F.S./10°C
Temp Effect on Zero: 0.1%F.S./10°C
Response frequency: 10kHz
Material: Alloy Steel
Impedance: 350Ω
Insulation: ≥5000MΩ/100VDC
Operating Voltage Range: 5-10v
Operating Temp Range: -20-80°C
Safe Overload: 120%
Maximum Overload: 150%
Cable Specifications: Φ3x2m
Cable Ultimate pull: 10kg
Package included:
1*Capsule Sensor
 |  |
 |  |
 |  |
 |
