UNIMIG HYPERARC 16TC LOW HYDROGEN ELECTRODES - 2kg

View product video

- All positional (except vertical down) welding
- Vacuum sealed packaging
- Use AC or DC power source
- Exceptional arc stability
- Unique twin coating extrusion process
- Low spatter levels
- Glassy slag easily removed from metal
- Easy to strike and re-strike
- Smooth bead appearance


The new twin coated 7016 HYPERARC 16TC Low Hydrogen Electrode features excellent arc stability, low spatter levels and easy slag removal. With its all positional capabilities (except vertical down) it is the optimum choice when high quality welding is required. The ideal hydrogen controlled electrode for welding carbon, carbon-manganese and low alloy high strength steels.

Product information

What You Get:
UNIMIG Hyperarc 16TC Low Hydrogen Electrodes
Choose Size: 2.6mm / 3.2mm / 4.0 mm
Choose Amount:
1kg / 2kg / 6kg / 12kg
*FREE $30 Welding Hood with 12kg Purchase*
Packaged: All vacuum sealed

Features of Hyperarc Electrodes:
All positional (not vertical down) welding
Use AC or DC power source
Exceptional arc stability
Unique twin coating extrusion process
Low spatter levels
Slag easily removed from metal
Easy to strike and re-strike
Specifications:
Part No: U63009
Electrode Length (mm):
2.6mm = 350mm
3.2mm = 350mm
4.0mm = 400mm
Welding Range:
2.6mm = 50-90A
3.2mm = 80-130A
4.0mm = 110-180A
Yield Stress: 470 MPa
Tensile Strength: 583 MPa
Elongation: 29%
Impact Test: 93J @ -20°C
Weight: 2kg
Application: Structural Steel Fabrication / Pressure Vessel welding / Pipe welding / Repair work for Agriculture and machinery / Earthmoving equipment repairs / Layering, “Buttering”
Classification:
AS/NZS ISO 4855: B E4916 A U H10
AWS A5.1: E7016
Features:
The new twin coated 7016 HYPERARC 16TC Low Hydrogen Electrode offers total performance and features excellent arc stability, low spatter levels and easy slag removal.
With its all positional capabilities (except vertical down) it is the optimum choice when high quality welding is required.
The ideal hydrogen controlled electrode for welding carbon, carbon-manganese and low alloy high strength steels.
Applications: Structural Steel Fabrication / Pressure Vessel welding / Pipe welding / Repair work for Agriculture and machinery / Earthmoving equipment repairs / Layering, “Buttering”
Smooth running, basic low hydrogen electrode, using AC or DC power sources. It has exceptional arc stability and weldability and delivers high-quality weld deposits with reliable notch toughness to -40°C.
High arc stability.
Easy arc strike and restrike.
All positional (except vertical down).
Easy slag removal: The slag on the HYPERARC 16TC forms with the glassy appearance only a true twin coated electrode can provide. This means it is easily removed, has less clean up, has a better presented bead profile, and provides less downtime.
Low spatter = less downtime.
Smooth bead appearance.
High arc force=Increases penetration
Each packet of HYPERARC 16TC’s comes vacuum sealed and supplied in 2kg packets. This ensures the electrodes are dry and ready to use straight out of the packet, as well as reducing wastage in unused electrodes.
Reduces contamination and wastage.
