Adjustable Single Electric Table Lift Desk Frame, 120 VAC, 25.5" Stroke, 180 lbs., 3 Steps - Progressive Automations - FLT-01 (Single)

This table lift set includes one lifting column, one control box and one remote. It has a 25.5" stroke and is able to lift up to 180 lbs. The remote can program up to four preset positions for the table lift providing simple motion control. No table top included.

   About this item

  • A complete one-leg lift system with all the necessary components to build an automated workstation. Simply combine it with a tabletop of your choice to make your own height adjustable standing desk.

  • The FLT-01 is ideal for smaller tabletops and desks that can be used for personal workstations. It has a starting height of 23.1” and can be fully extended to reach 48.6"

  • Other Applications – The single leg table lift is designed for use in homes and office environments but is not limited to them. It can be used to lift loads of up to 180 lbs and has a built-in base for easy installation.

  • FEATURES – With the wired remote, you are able to program up to four preset height positions for the table lift. Once a height position is saved, the table lift will automatically raise or lower to the set position with the press of a button. The soft start and stop operation ensure a smooth and noiseless transition from sitting to standing positions.

  • SUPERB QUALITY GUARANTEED or your MONEY BACK! Progressive Automations actuators are quiet, clean, non-toxic and energy efficient. Our products can also be designed to suit your requirements and our support team of engineers is skilled to help you with your product integration.

Specifications:

Input Voltage: 120 VAC

Output power: 24 VDC

Load: 180 lbs

Speed: 1.57"/s

Stroke: 25.5 inches

Protection class: IP51

Install size:23.1 inches (fully retracted); 48.6 inches (fully extended)

Type of duty: 10%
