Proprietary Non Resonance Polycarbonate/Glass Fiber Basket
Chrome Push Terminals
Optimally Designed for Both Small Sealed or Ported Enclosures
Specifications
Nominal Impedance: 4-ohm
BL: 14.38
Inputs: Single Coil
Subwoofer Frequency Range: 26 Hz - 300 Hz
Voice Coil Size: 2 in
Material: Non Pressed Paper
Magnet Size: 186 oz
Sensitivity (1W / 1M): 86.78 dB
Motor Structure: 186 oz
Cutout Diameter: 11 1/16" (281mm)
Mounting Depth: 5.75 in
Xmax: 8 mm
Spl: 86.78 dB
No: 0.287%
Qts: 0.421
Qes: 0.462
Qms: 4.794
Mms: 172.16 g
Cms: 195 uM/N
Vas: 66.37 Ltr
SD: 490.87 sqCM
Fs: 27.5 Hz
Test Impedance: 3.21-ohm
VC Impedance: 4-ohm
Size: 12 in
Sensitivity: 86.78 dB
Frequency Response: 26 Hz - 300 Hz
Voice Coil Size: 2 in
Power Handling (RMS/Peak): 400 / 800 watts
