Powerbass ACS-1000D 1000W 1-Channel Compact Mono Class D Amplifier

ACS Series Class D Mono 2000W 1 Ohm Amplifier by PowerBass®. PowerBass is pleased to introduce newest series of Class A/B full range and Class D bass amplifiers. Borrowing from classic ASA series, these new amplifiers offer the most desired features in the most compact chassis allowable. To accomplish this they selected SMD parts and engineered a brand new 6 oz/kg high density heat sink engineered for maximum efficiency and cooling. The result a line-up of two, four and mono channel models that offer great performance and fantastic value. Ultra efficient, the ACS amplifiers produce plenty of low distortion high fidelity audio in a footprint small enough to fit nicely in nearly any vehicle. If you are seeking the perfect mix of performance and value look no further.

Features:

• 1,000 Watt High Efficiency Class D Design
• 1-Ohm Stable Mono Block Amplifier
• MOSFET Power Supply
• High Level (Speaker)/Low Level (RCA) Input
• Remote Soft Delay Turn On/Off Circuit
• Variable Low Pass Electronic Crossover
• Selectable 12dB Bass Boost EQ
• Variable Gain Control
• Remote Level Control Port (for optional PB-GAIN1 controller)
• Protection Circuit: Impedance Over-load, Speaker Short, Circuit, Thermal Overheating, and DC Output
• Made to maximize performance and sound of your vehicle
• Built with superior quality components to last you for years to come
• Fusion of dazzling clarity and powerful sound

Specifications

• Class: Class D
• Channel: Mono
• MAX Power: 2000W
• Impedance: 1 Ohm
• Channels (mono): 1
• Crossover Slope: 12 dB
• Depth: 12.0"
• Dimensions (in Inches): 12.0" x 7.1" x 2.0"
• Equalization Boost/Cut: Switchable 0/12 dB @ 45Hz
• Frequency Response: 10 Hz - 250 Hz
• Height: 2.0"
• High-Pass Crossover Freq: N/A
• Input Sensitivity: 0.25 V - 6.0 V
• Inputs: RCA, 1 Pair Input, 1 Pair Speaker Level Input
• Low-Pass Crossover Freq: Variable 30 Hz - 250 Hz
• Operating Voltage: 14.4 V
• Peak Power: 2000 watts
• Power @ 1 Ohm: 1000 watts x 1
• Power @ 2 Ohm: 600 watts x 1
• Power @ 4 Ohm: 400 watts x 1
• Power Supply: Unregulated PWM
• Signal-to-Noise Ratio: >90 dB
• Strapped Output Power @ 2ohms: N/A
• Subwoofer EQ Frequency: 45 Hz
• Switchable Subwoofer EQ: 0 / +12 dB @ 45 Hz
• Total Harmonic Distortion: 0.5% @ 1,000 watts
• Variable Subsonic Freq: Variable 15 Hz - 50 Hz
• Variable Subwoofer EQ: Switchable 0/+12 dB
• Width: 7.1"
