150W, Mains to 24Vdc Triac dimmable LED driver

Model: ELED-150-24T

- Triac dimmable (dimmable with leading edge/trailing edge)
- Constant Voltage Design, 24Vdc
- Protections: Short circuit/ Over Loading/ Over Current
- Suitable for LED lighting and moving sign applications

Output DC voltage: 24V
Rated current: 6.25A
Voltage accuracy: ±0.5V
Rated power: 150W
Min. load: 15W
Input Voltage Range: 180-250VAC (90-130Vdc)
Frequency Range: 47-63HZ
Power Factor ( Typ.): PF ≥ 0.6/220V
Full Load Efficiency (Typ.): 86%
AC Current (Typ.): 1.05A
Leakage current: <0.70mA/220V
Short Circuit: Hiccup mode, recovers automatically after fault condition is removed.
Over load: ≤120%
Over current: ≤1.4L out
Working TEMP.: -40~+60°C
Working Humidity: 20~99% RH, non-condensing
Storage TEMP.-40*C - +80*V
Humidity: ±0.03%/°C (0-50°C)
Vibration: 10~500Hz, 5G 10min./1 cycle, period for 60min. each along X,Y,Z axes.
Safety standards: EN60950-1, IP66
Withstand voltage: I/P-O/P:3.75KVAC
Isolation resistance: I/P-O/P I/P-FG O/P-FG: 100MΩ/500VDC/25°C/70%RH
EMC EMISSION: Compliance to EN55015, EN61000-3-2 ( ≥ 50%load) EMC IMMUNITY: Compliance to EN61000-4-2,3,4,5,6,8, 11, EN61547, A light industry level
Dimensions: 256*78*47mm (L*W*H)
Packing: 1.7Kg

NOTE: ELED-150-24T prefers leading edge dimmers
