ADSL Centralised Filter 6 way

The Pressac Centralised DSL Filter is designed to plug into a standard NTE5 residential telephone outlet.

It provides a straight through connection for DSL modem connection via a shuttered RJ45
socket as well as a filtered telephone socket.

A 6 way IDC connector is provided for onward connection (filtered) of extension telephones and hard wiring of a DSL modem if required.

Connection ports

• Line : BS6312 approved integrated 431A BT plug
• Telephone : Connection via BS6312 4 way BT socket
• Modem : Direct coupled RJ45 (RJ11compatible) socket
• Extension / ADSL wiring : 6 way IDC connector

Key Features

• V0 rated material colour matched to BT 1P white
• Tested by BT to SIN 346 Issue 2.2
• Compatible with Calling Line Identification working
• CE Marked – BS EN 55022

With the centralised filter system, the filter becomes an integral part of the wall socket providing a tidy looking fixture with the added benefit of negating the need for subsequent extension sockets to have microfilters plugged into them.

Pressac Part Number 60.10908.PS9XX
