Jubilee Hi-Grip Hose Wing Clip JCS Worm Drive 304 Steel Clamp Multipack Set

Jubilee Hi-Grip Hose Wing Clip JCS Worm Drive 304 Steel Clamp Multipack Set

£
0.99 - 30.55

Specifically designed for frequently removed hoses, the unique dovetail locking and side lugs of the wing plate ensure excellent sealing and longevity. The soft plastic wing plate cover is kinder to unprotected fingers. JCS Hi-Grip general purpose worm drive hose clips are widely regarded for their quality, durability and ability to withstand a great deal of abuse. They are manufactured to exceed BS5315, have BSI Kitemark and NATO approval, and exceeds all operational requirements of the relevant DIN and SAE standards.Standard (W1) Hose clips are used for a wide variety of domestic, automotive and industrial applications, the standard Hi-Grip hose clip is made from heavily zinc plated mild steel with additional protection from a passivation layer.

  • Bevelled Edges Protect Hose
  • Exceeds BS5315

* Please note - if ordering the sample product, then you do so on the understanding that you will not be sent the smallest size in this range and the 99p sample is just that, a sample of a clamp unrelated to this product range. Don't order the sample if you need a specific size and product!



Diameter Range (A) mm 9.5 - 90.0

Diameter Range (A) inch 0.37 - 3.54

Band Width (B) mm - inch 9.0 - 0.35

Band Thickness (C) mm - inch 9.0 - 0.028

Torque Setting Nm – lb inch 3 - 26

Screw mm A/F 7.0

Band/Housing Material Stainless 304

Brand Hi-Grip

Manufactured By JCS

Manufactured according to BS5315

Country of Manufacture United Kingdom

Hazardous Goods No

RoHS Compliant Yes
