Pneumatic solenoid valve 4V230-06 Double coil
5/3 way control valve with Plug type red LED light
Voltage: 110V AC ,220V AC ,380V AC ,24V AC ,12V DC ,24V DC .
1.Specification
| Product Name | Solenoid Valve |
| Model No. | 4V230-06 |
|
Fluid |
40 Micron Filtered Air |
|
Operation Type |
Internal Piloted |
| Port Size | G1/8",G1/4" |
| Working Pressure | 0.15~0.8MPa |
| Type | 5 Way 3 Position |
| Power Consumption | DC24V,DC12VDC,220VAC,110VAC |
| Temperature | 60°C |
| Maxi. Withstand Pressure | 1MPa |
| Threaded Port Size(Approx) | |
| Overall Size(Approx) | 15.5 x 5.5 x 2.2cm / 6.1" x 2.2" x 0.9" (L*W*H) |
| Color | White, Black |
| Net Weight | 400g |
| Package Content | 1 x Solenoid Valve |
Description:
- With solenoid operated for control appropriate flow and direction, provide great performance.
- Stury body have a long lifespan, perfect for electrically driven pneumatic power control.
- Two Coil 2 position solenoid valve.
-
