Murrelektronik 4000-68000-4500001 MODLINK MSDD SINGLE COMBI INSERT GERMANY

Product Description

Description

1× Germany (VDE) white
1× RJ45, 8-pole metal, CAT6A (female/female)
1× RJ45 cut-out
CE
China RoHS 50

Device protection | Electrical
Degree of protection (EN IEC 60529) IP20
Mechanical data | Mounting data
Height 87,5 mm
Width 50,7 mm
Depth 43 mm
Environmental characteristics | Climatic
Operating temperature min. -5 °C
Operating temperature max. 50 °C
Ambient temperature (storage, transport) -10 °C … 60 °C
Shielding plate
Connection information Threaded hole M4
Tightening torque 0,9 Nm
Tightening torque tolerance ± 0,1 Nm
Germany (VDE)
Connection Spring clamp terminals FK
No. of poles 2 + PE
Connections per pole 2
Protection contact present Yes
Connection cross section max. 2,5 mm²
AWG number max. 14
Operating voltage AC 250 V
Operating current 16 A
RJ45-5
Family construction form RJ45
Locking techniques Snap-in connector
Cable category min. Cat6a
Family type Back side RJ45
Operating voltage AC max. (UL-listed) 30 V
Operating voltage DC max. (UL-listed) 42,4 V
Current operating max. (UL) 175 mA

URL Webshop https://shop.murrelektronik.com/4000-68000-4500001
GTIN 4048879600880
EU-Customs tariff number 85366990
US-Customs tariff number 8536694020
ECLASS-6.0 27189217
ECLASS-6.1 27189217
ECLASS-7.0 27189217
ECLASS-7.1 27189217
ECLASS-8.0 27189217
ECLASS-8.1 27189217
ECLASS-9.0 27182806
ECLASS-9.1 27189217
ECLASS-10.0.1 27182806
ECLASS-10.1 27182806
ECLASS-11.0 27182806
ECLASS-11.1 27182806
ECLASS-12.0 27182806
ECLASS-13.0 27182806
ECLASS-14.0 27182806
ETIM-5.0 EC002625
ETIM-6.0 EC002625
ETIM-7.0 EC002625
ETIM-8.0 EC002625
ETIM-9.0 EC002625
ETIM-10.0 EC002625
customs tariff number 85366990
EAN 4048879600880
Packaging unit 1
