Murrelektronik 56766 CUBE67+ I/O Extension Module DIO12 IOL4 V1.1 E 8xM12
Description
Expansion module
DIO12 IOL4 (E) - 8× M12
IO-Link Master V1.1.2
Digital inputs/outputs (multifunctional)
Compatible with:
56521 PROFIBUS
56526 PROFINET
56535 EtherNet/IP
Connection cables are in the online shop under "Connection Technology".
Housing fully potted.
Cube67+ modules can only be operated on Cube67+, EtherNet/IP, PROFIBUS + PROFINET bus nodes.
DIO12 IOL4 (E) - 8× M12
IO-Link Master V1.1.2
Digital inputs/outputs (multifunctional)
Compatible with:
56521 PROFIBUS
56526 PROFINET
56535 EtherNet/IP
Connection cables are in the online shop under "Connection Technology".
Housing fully potted.
Cube67+ modules can only be operated on Cube67+, EtherNet/IP, PROFIBUS + PROFINET bus nodes.
Technical Data
Electrical data | Supply
| Norm operating voltage | IEC/EN 61131-2 |
|---|---|
| Operating voltage US DC | 24 V |
| Total current US max. | 4 A |
| Operating voltage UA DC | 24 V |
| Total current UA max. | 4 A |
| Current consumption max. | 100 mA |
Electrical data | Input
| Sensor current US per input max. | 0,2 A |
|---|---|
| Sensor current US per IO-Link port max. | 0,7 A |
| filter time | 1 ms |
| Type input | for 3-wire sensors or mechanical switches, PNP |
Electrical data | Output
| Output current per pin max. | 1,6 A |
|---|---|
| Overload resistant | Yes |
| Short-circuit protected | Yes |
| Lamp load | 30 W |
Industrial communication | IO-Link
| type | 4× Master |
|---|---|
| Port Class | A, B |
| revision ID | V1.1.2 |
| transmission rate | COM1, COM2, COM3 |
| process data length input | 32 byte |
| process data length output | 32 byte |
| Automatic baudrate detection | automatic |
Diagnostics
| Actuator warning | per channel via LED and BUS |
|---|---|
| Short circuit diagnosis | Yes |
| Overload diagnosis | Yes |
| Diagnostic via BUS | per module and channel |
| Diagnostic via LED | per module and channel |
| LED display | Ethernet connection/data traffic |
| IO-Link events | Undervoltage supply, No voltage |
Device protection | Electrical
| Degree of protection (EN IEC 60529) | IP67 |
|---|
Mechanical data | Mounting data
| Height | 126 mm |
|---|---|
| Width | 30 mm |
| Depth | 34,5 mm |
| Suitable for mounting type | 2-hole screw mounting |
Environmental characteristics | Climatic
| Operating temperature min. | 0 °C |
|---|---|
| Operating temperature max. | 55 °C |
| Ambient temperature (storage, transport) | -20 °C … 75 °C |
Connection data
Connection types
| Connection type 1 | Bus In |
|---|---|
| Connection type 2 | Bus Out |
| Connection type 3 | DIO |
| Connection type 4 | DIO / IO-Link |
Connection type 1-1
| Family construction form | M12 |
|---|---|
| No. of poles | 6 |
| Coding | A |
| Gender | male |
| Color contact carrier | black |
| PIN 1 | 24 V DC (UA) |
| PIN 2 | 24 V DC (US) |
| PIN 3 | 0 V |
| PIN 4 | Bus internal |
| PIN 5 | Bus internal |
| PIN 6 | 0 V |
Connection type 2-2
| Family construction form | M12 |
|---|---|
| No. of poles | 6 |
| Coding | A |
| Gender | female |
| Color contact carrier | black |
| PIN 1 | 24 V DC (UA) |
| PIN 2 | 24 V DC (US) |
| PIN 3 | 0 V |
| PIN 4 | Bus internal |
| PIN 5 | Bus internal |
| PIN 6 | 0 V |
Connection type 3-3
| Family construction form | M12 |
|---|---|
| No. of poles | 5 |
| Coding | A |
| Gender | female |
| Color contact carrier | black |
| PIN 1 | 24 V DC (US) |
| PIN 2 | DI / DO / Diag |
| PIN 3 | 0 V |
| PIN 4 | DI / DO |
| PIN 5 | PE |
Connection type 4-4
| Family construction form | M12 |
|---|---|
| No. of poles | 5 |
| Coding | A |
| Gender | female |
| Color contact carrier | black |
| PIN 1 | 24 V DC (US) |
| PIN 2 | DI / DO / Diag |
| PIN 3 | 0 V |
| PIN 4 | DI / IO-Link |
| PIN 5 | 0 V |
Commercial data
| URL Webshop | https://shop.murrelektronik.com/56766 |
|---|---|
| GTIN | 4048879581431 |
| EU-Customs tariff number | 85389099 |
| US-Customs tariff number | 8538908180 |
| Compatible with: | 56521; 56526 |
| ECLASS-6.0 | 27242604 |
| ECLASS-6.1 | 27242604 |
| ECLASS-7.0 | 27242604 |
| ECLASS-7.1 | 27242604 |
| ECLASS-8.0 | 27242604 |
| ECLASS-8.1 | 27242604 |
| ECLASS-9.0 | 27242604 |
| ECLASS-9.1 | 27242604 |
| ECLASS-10.0.1 | 27242604 |
| ECLASS-10.1 | 27242604 |
| ECLASS-11.0 | 27242604 |
| ECLASS-11.1 | 27242604 |
| ECLASS-12.0 | 27242604 |
| ECLASS-13.0 | 27242604 |
| ECLASS-14.0 | 27242604 |
| ETIM-5.0 | EC001597 |
| ETIM-6.0 | EC001597 |
| ETIM-7.0 | EC001597 |
| ETIM-8.0 | EC001597 |
| ETIM-9.0 | EC001597 |
| ETIM-10.0 | EC001597 |
| customs tariff number | 85389099 |
| EAN | 4048879581431 |
| Packaging unit | 1 |
