Murrelektronik 50003 Active Controlled Rectifier 22.5 mm Spring Clamp

Product Description

Description

24 V DC (ON: > 16 V DC; OFF: < 12 V DC)
OUTPUT: 180, 205, 215 V DC
Spring clamp terminals
CE
cURus
UKCA

Electrical data | Supply
Power frequency 50/60 Hz
Network form star
Electrical data | Input
Voltage type input AC
Nominal input voltage AC 230 V … 400 V
Input voltage 3 AC 480 V
Control voltage IN DC min. 16 V
Input voltage OFF DC max. 12 V
Current input AC max. 0,8 A
Leakage current max. 10 mA
Control voltage DC min. 0 V
Control voltage DC max. 30 V
Control current 18 mA
Power loss 3,3 W
Electrical data | Output
Output voltage 205 V DC (230 V AC); 180 V DC (400 V AC); 215 V DC (480 V AC)
Output current 0,75 A
Measuring method output current max. peak value
Switching frequency max. 2,5 Hz
Power loss 3,3 W
Output current in parallel operation max. 1.100 mA
Measuring method output current in parallel operation max. peak value
Diagnostics
Status indication LED green
LED display Control voltage applied
Device protection | Electrical
Installation height max. ASL 2.000 m
Degree of protection (EN IEC 60529) IP20
Short-circuit protected No
Pollution Degree 2
Overcurrent proctection external Motor protection switch max. 6.3 A, tested with PKZM01-6,3
Reverse polarity protection (Control input) Yes
Rated surge voltage 2,5 kV
Rated insulation voltage (Main circuit - earth) 300 V
Rated insulation voltage (Control circuit - main circuit) 500 V
Mechanical data | Material data
housing PC
Color housing black
Mechanical data | Mounting data
Net weight 100 g
Height 82,5 mm
Width 22,5 mm
Depth 114,3 mm
Mounting method geschnappt
Suitable for mounting type Mounting rail TH35-15, (EN 60715)
Environmental characteristics | Climatic
Ambient temperature (operation) -25 °C … 55 °C
Ambient temperature (storage, transport) -25 °C … 55 °C
Relative humidity (operation) 5 % … 85 %
Additional condition temperature range no dew formation
Assembly location Interior
Technical Data | Reliability
MTTF (EN/IEC 61709, EN ISO 13849-1, SN 29500) 442 a @ 40 °C
Environmental product conformity
REACH ((EC) 1907/2006) compliant
REACH SVHC ((EC) 1907/2006) Lead (Pb) CAS 7439-92-1
RoHS (2011/65/EU, (EU) 2015/863) compliant
RoHS-Exemption (2011/65/EU) keine RoHS-Ausnahme, 7(c)-I
China RoHS (SJ/T 11364, GB/T 26572) EFUP-20
California Proposition 65 compliant
WEEE (2012/19/EU) Category 5
Halogen content not halogen-free
Lead-free No
Conformity
Product standard EN IEC 60947-4-3
CE 2014/30/EU, 2011/65/EU, 2014/35/EU
UKCA The Electromagnetic Compatibility Regulations 2016, The Electrical Equipment (Safety) Regulations 2016, The Restriction of the Use of Certain Hazardous Substances in Electrical and Electronic Equipment Regulations 2012
Approvals
UL Listed (US, CA) E205946

Connection types
Connection type 1 X1
Connection type 2 X2
Connection type 3 X3
Connection type 4 X4
Connection type 1
Family construction form terminal
No. of poles 4
Gender female
Connection Spring clamp terminals FK
PIN 1 L 1
PIN 2 L 1
PIN 3 N
PIN 4 N
Connection type 2
Family construction form terminal
No. of poles 4
Gender female
Connection Spring clamp terminals FK
PIN 1 S -
PIN 2 NC
PIN 3 L 2
PIN 4 L 2
Connection type 3
Family construction form terminal
No. of poles 3
Gender female
Connection Spring clamp terminals FK
PIN 1 DC +
PIN 2 S +
PIN 3 S -
Connection type 4
Family construction form terminal
No. of poles 8
Gender female
Color contact carrier green
Connection Spring clamp terminals FK
PIN 1 SL
PIN 2 SL
PIN 3 SR
PIN 4 SR
PIN 5 0 V
PIN 6 0 V
PIN 7 0 V
PIN 8 0 V

Manufacturer name Murrelektronik GmbH
Manufacturer address Grabenstraße 29, 71570 Oppenweiler, GERMANY
URL Webshop https://shop.murrelektronik.com/50003
GTIN 4048879404150
EU-Customs tariff number 85044083
US-Customs tariff number 8504409550
Intended use For professional use only, Indoor use only
Suitable for outdoor use No
ECLASS-6.0 27371604
ECLASS-6.1 27040390
ECLASS-7.0 27040390
ECLASS-7.1 27040390
ECLASS-8.0 27040390
ECLASS-8.1 27040390
ECLASS-9.0 27040390
ECLASS-9.1 27040390
ECLASS-10.0.1 27040390
ECLASS-10.1 27040390
ECLASS-11.0 27040390
ECLASS-11.1 27040390
ECLASS-12.0 27040390
ECLASS-13.0 27040390
ECLASS-14.0 27040390
ETIM-5.0 EC001504
ETIM-6.0 EC001504
ETIM-7.0 EC001504
ETIM-8.0 EC001504
ETIM-9.0 EC001504
ETIM-10.0 EC001504
Contents per packing unit 1
customs tariff number 85044083
EAN 4048879404150
Packaging unit 1
