Idoing 9" Android 13 Car Radio for Nissan Terra Frontier 2018-2022
Key Features
OEM Support: Factory Backup / 360 Camera | Steering Wheel Control | Premium / Basic sound system
Built-in Apple Carplay & Android Auto | DSP | Bluetooth Multimedia Head Unit
Android 13 System: Latest OS with high-speed performance.
Advanced DSP: 32-band EQ with TDA7851 chip for superior audio quality.
Dual Satellite GPS: Built-in GPS + GLONASS for accurate navigation
Versatile Support (optional): DAB+, OBD2, Rear View Camera, and DVR support.
| Technical Specifications | |||
|---|---|---|---|
| Brand | Idoing | Multi media Parameters | |
| Din | 1 din | Music Format | MP3,WMA,AAC,RM,FLAC etc |
| Operating System | Android 13 system | Video Format | MPEG-1/2/4,H264,H263,VC1,RV,H265,DivX, Sorenson SparK,Spark,VP8,AVS Streamhellip |
| CPU | ARM 6NM, Octa core 2.7 GHZ | Picture Format | JPG/BMP/JEPG/GIF/PNG |
| DDR |
SAMSUNG DDR3 6GB
|
Radio Parameters | |
| EMMC | 128GB | Frenqency Range |
FM:76.0MHz-108.0MHz AM: 522KHz-1620KHz |
| Max External Memory | 128GB | Country | Australia,Europe,Russia,USA1,USA2, |
| Radio | FM/AM | Amplifer Parameters | |
| Screen | 2.5D IPS Full Touch Screen | Test Voltage | 14.4V |
| Screen Resolution | 1280*720 / 2000*1200(option) | Max output power | 4*48W |
| GPU | ARM R Cortex - A76 up to 2.7GHz | GPS Parameters | |
| Radio IC | NXP 6686 | Support Map | Map:google/here/sygic/tomtom/waze/igo... |
| Power amplifier IC | TDA7851 | Main Frenqency | 1.575GHz |
| Bluetooth IC | BC 5.0 | WIFI Parameters | |
| Power supply | 4*45W max | RF Power | 15dBM |
| Video Decoder | 1080P HW | Power supply | Vcc_3.3V |
| DSP | 32-Bands Equalisation | Suppoted Protocol/standard | IEEE802.11B/g/n compatible WLAN |
| OSD Language |
English,Russian,Portuguese,Arabic,Italian,German,
French...for up to 70 national languages
|
Interface type | USB2.0 |
| Built in |
Wifi,GPS+GLONASS,Bluetooth,MIC,Split screen,
Mirror Link for andriod phone and iphone,WIFI
|
Frequency | 2.4-2.484GHz |
|
Support |
Support external Car-Play,Andriod Auto,DAB+,
Bluetooth,OBD2,Reverse Camera,USB DVR
|
Modulation | OFDM/DBPSK/DQPSK/CCK |
Important Compatibility Note
All car models listed are for reference only. Please note that the same car model may have different original radio/CD systems depending on the factory or country. We strive to send the correct product, but please verify your dashboard layout before purchasing to avoid return shipping costs and taxes.
