Jabsco P601J-215S-3A 3/4" HD6 ParMax Heavy Duty Pressure Controlled Pump 12V
Model: ParMax | P601J-215S-3A
With 90 Degree Quick Connect Strainer
The Jabsco Par-Max HD6 Heavy-Duty Marine Freshwater Delivery Pump (Model P601J-215S-3A) is a robust, 12-volt diaphragm pump engineered for demanding marine water systems. Delivering up to 5 GPM (22.7 L/min) at 40 PSI (2.8 bar), this pump offers seamless, on-demand performance via its integrated, sealed pressure switch. With a heavy-duty build featuring a fiber-reinforced polypropylene upper housing and cast aluminium lower housing, the pump ensures exceptional durability. It is self-priming, can run dry without damage, and includes a built-in bypass to reduce cycling for smoother flow—all wrapped in a quiet, efficient design.
Applications
- Marine freshwater systems — ideal for galley faucets, showers, and washdown stations
- Boats and caravans — provides reliable freshwater delivery for multi-outlet systems
- General-purpose water transfer — well-suited for applications needing pressure and flow control in compact spaces, such as camper or mobile water systems.
Specifications
| Brand | Jabsco |
| Range | Parmax |
| Max Flow Rate | 22.7 LPM | 6 USGPM |
| Self Priming Capability | 2.1 Metres |
| Temperature Range | 0 - 60°C | 32 - 140°F |
| Pump Size | 19mm | 3/4" |
| Port Fittings | 2 x 3/4" (19mm) Straight Hosebarb |
| Max Operating Pressure | 40 PSI | 2.8 bar |
| Max Inlet Pressure | 30 PSI | 2.1 bar |
| Voltage | 12v |
| Diaphragm Material | Santoprene |
| Check Valve Material | EPDM |
| Fuse Size | 25 (amp) |
| Packaged Dimensions | L:39.4 x H:15.2 x W:14 cm |
