220V Din Rail Adjustable Over & Under Voltage Protective Device Delay Auto reset

Feature

1. Using high-quality materials, the quality is guaranteed
2. This product is suitable for single-phase loads with AC 230V, 50/60Hz, rated working current of 40A or 63A or below 80A
3. Mainly used for overvoltage, undervoltage or overcurrent protection of input of residential household boxes or single-phase electrical equipment distribution lines
4. When the circuit has overvoltage or undervoltage, overcurrent problems, the product can instantly cut off the power supply to protect the electrical equipment from damage 5. When the circuit voltage returns to normal, the protector can automatically turn on the power
6. When the power supply is normal, the green indicator light is displayed; when the power supply is over-voltage or under-voltage, the red indicator light is displayed.

parameter;
Power supply: 230VAC 50/60Hz
Maximum load power: 1~40A or 1~63A or 1~80A adjustable (default: 40A or 63A or 80A)
Overvoltage protection value range: 221 300 V～～OFF (default: 280V)
Surge recovery voltage range: 220v-299v (default: 250V)
Overvoltage protection action time: 0.1s～10s (default: 0.1s)
Low voltage protection value range: 219V--150V - power off (default: 160V)
Undervoltage recovery voltage range: 151v-220v (default: 180V)
Undervoltage protection action time: 0.1s～10s (default: 0.1s)
Recovery delay time: 2s～120s (default: 60s)
Boot delay time: 2s～10s (default: 2s)
Power consumption: <2W
Motor life: 100,000 times
Mounting: 35mm DIN rail

Note: When connecting the product for the first time, you need to wait for about 1 minute, and the product can work after the red light goes out.

Package list:
Undervoltage protector*1"
