Enviroflex EFO-120-TC 2" Tri-Clamp Centrifugal Impeller Brewery Pump 400v 300LPM
Model: EFO | EFO-120-TC
The Enviroflex EFO-120-TC is a high-quality semi-open impeller centrifugal brewery pump built with stainless steel components. It features a 103 mm diameter semi-open impeller capable of handling solids up to 18 mm. The pump is equipped with 2” x 2” Tri-Clamp (64mm OD Ferrule) fitting. A 3/8" UNC vent/drain plug is included for easy access and cleaning. The unit is powered by a 0.9 kW electric motor (400 V / 3 / 50 Hz) and is rated at 2,900 rpm (2 poles). It delivers a maximum head of 11 m, a maximum flow rate of 300 L/min, and can withstand pressures up to 116 psi / 8 bar. The pump’s maximum temperature rating is 110 °C (or 95 °C for water-based products). Its mechanical seal is hard-faced, using TC vs SiC / FKM (Viton) as standard.
Features
- Food-processing washdown systems — ideal for cleaning vegetables, meats, fish, and shellfish
- Industrial washing and finishing — suitable for end-of-cycle cleaning of metal components, bottles, cans, jars, glassware, crates, and baskets
- Commercial and catering equipment — for use in communal dishwashers, glasswashers, cup washers, and spray-booth systems
- General fluid management — efficient in liquid transfer, circulation, and drainage operations
- Brewery operations — perfect for transferring hot wort, beer, and cleaning-in-place (CIP) solutions
Specifications
| Brand | Enviroflex |
| Range | EFO |
| Model | EFO-120-TC |
| Pump Type | Centrifugal Pump |
| Impeller Material | Stainless Steel |
| Pump Head Material | Stainless Steel |
| Porting | 2” x 2” Tri-Clamp (64mm OD Ferrule) |
| Voltage | 400v |
| HP | 1.2 HP |
| KW | 0.9 kW |
| Maximum Head | 11 Metres |
| Flow Rate | 300 LPM |
| Maximum Pressure | 116 PSI / 8 bar |
| Maximum Temperature | 110 degrees Celsius (95 degrees Celsius on water based products) |
| Motor Info | 2 Poles - 2900 RPM |
| Maximum Solids | 18mm |
| Mechanical Seal | TC vs SiC/FKM (Viton) |
