Specifications
Processor System
CPU •Intel 12th Alder Lake Processor Default Core i5-1235U 8 Cores Process
TDP 65W
Memory 2 x DDR4 SO-DIMM Socket (Up to 64G)
Chipset By CPU
Graphics By CPU
LAN Chipset 1 x Realtek RTL8111H Gigabit LAN
Audio Cmedia HS-100B
Watch Dog Yes
AC Recovery In BIOS
Front I/O
Power Button
1 x Power Button, 1 x Reset Button
Audio 1 x Mic-in, 1 x Line-out
Video Output 1 x HDMI 2.0, 1 x Display Port 1.4
LAN 1 x Realtek RTL8111H Gigabit LAN
USB 3 x USB 2.0, 3 x USB 3.2
Rear I/O (OPS)
Power 1 x DC Jack
Video Output 1 x HDMI (Need a 4K @ 60Hz Sub-card)
USB 2 x USB 2.0, 1 x USB 3.2
Audio 1 x Line-out
Switch 3 x JSW
Serial Port 1 x TTL (Output via the Rear JAE End)
Storage
Type 1 x 2.5-inch HDD/SSD
1 x M.2 for SSD (M key, Type: 2280, PCIe 4.0 x 4)
Expansion
M.2 1 x M.2 for Wi-Fi (E key, Type: 2230)
Power Requirement
Power Adapter 19V
DC Jack 5.5mm, 2.5mm
Environmental
Operating Temp 0°C~50°C
Non-Operating Temp -20°C~70°C
Humidity 10%~90%
Mechanical
Material Aluminium Alloy
Dimension 118 x 180 x 30mm (L x W x H) (EU)
195 x 180 x 30/42mm (L x W x H) (GB)
Weight 1.50kg
Mounting None
WiFi Antenna Single Antenna by Default
Packaging Dimension 282 x 257 x 79mm
Kensington Lock Yes
Cooling Mode Fan
OS Support :OS Windows 10, Windows 11, Linux
Operating System
Packing
1 x Mini PC
1 x Power supply (adapter and cord)
1 x VESA bracket & screws
1 x Color box

We are professional, we make products with heart.
Work with Qotom, after-sales service is worry-free.
Qotom Is A Professional R&D Manufacturer and Exporter of Mini PC Computers. OEM and ODM Orders Are Welcomed.
The More You Purchase, the price is more Advantage.
He is a Mini desktop computer:
Qotom Mini PC Work as normal desktop computer, only need connecting to monitor, keyboard and mouse to make a full computing system,Can be configured as a firewall, LAN or WAN router, VPN device, DHCP server, DNS server, etc.
Mini PC can be applied in multiple scenarios:
Qotom Mini PC can be used in industrial control, industrial automation, smart retail, digital medical care, digital multimedia, network security, security monitoring, video conferencing, self-service terminals, machine vision, security inspection, cash registers, printers, ATM machines, office, etc.
